Optimal Design of Inlet Structure of High-Pressure Tubular Reactor Jacket

Abstract:

Flow characteristic of the desalted water influenced by three inlet structures in different diameter nomal tube, equal diameter nomal tube and tangential tube inlet of the jacketed tube in high-pressure tubular reactor was investigated based on computational fluid dynamics. The results show that the desalted water flow forms a region where the flow velocity is close to zero in the different diameter nomal tube structure and temperature of the desalted water in this region raises notablely. It is also found that the peaks of the shear stress occur at wall inside near inlet of the jacket. The other structures avoid in large extent advent of the former two phenomena and obviously reduce the shear stress value at wall. From the results, the second inlet structure is better than the third and the third better than the first.

• Periodical: Advanced Materials Research (Volumes 311-313)
• Pages: 1254-1257
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.311-313.1254
• Online since: August 2011
• Authors: Xiao Hui Ji, Wei Liu
• Keywords: High-Pressure Tubular Reactor, Inlet Structure, Jacketed Tube, Optimal Design

References

[1] Pogodin V K, Bezdelev V V.Causes of Failure of Polyethylene Reactor Seals and Equipment for Preparing them for Operation[J].Chemical and Petroleum Engineering. 1999, 35(11) :716-720

DOI: 10.1007/bf02365739

[2] Tatarinov V G, Arsen,ev V I.Effects of Nonstationary Hydrogen Diffusion on the Viability of a Polyethylene Reactor[J]. Chemical and Petroleum Engineering,2002, 38(3):118-123

[3] Hee-Jone Lee,Yeong-Koo Yeo.Modeling of Industrial High Pressure Autoclave Polyethylene Reactor Including Decomposition Phenomena[J].Korean Journal of Chemical Engineering,2000, 17(2):223-229

DOI: 10.1007/bf02707147

[4] Moroz V L, Lozovskii S Z.Reactors for the Production of High-pressure Polyethylene[J]. Chemical and Petroleum Engineering,1974, 10(9):850-855

DOI: 10.1007/bf01155551

[5] Mavridis H,Kiparissides C.Optimization of a High Pressure Polyethylene Tubular Reactor [J].Poly. Process. Eng.,1985,3:263-268

[6] YoonB J, Rhee H K A.Study of the High Pressure Polyethylene Tubular Reactor[J]. Chem. Eng. Commun,1985,34:253-258

[7] Ma Xiaoming.Analysis of Auto-ferrittage Elastic-plastic Boundary Radius for LDPE Ultrahigh Pressure Tubular Reactor [J]. Petro-Chemical Equipment,2009,38(3):63-65[In China]

[8] Liu Zengdian.Safety Analysis of In-service Tubular Reactor in High Pressure Polyethylene Plant [J]. Pressure Vessel Technology,1992, (1):11-19[In China]

[9] Bao Xingfang.Test of In-service Tubular Reactor in High Pressure Polyethylene Plant [J]. Petro- Chemical Equipment Technology,1994, (1):16-19[In China]

[10] Liu Wei.Analysis of Failure Mechanism and Measure of High-pressure Polythene Reactor [J]. Petro-Chemical Equipment,2009,38(6):89-91[In China]
