Progressive Damage and Failure Analysis of Fiber-Reinforced Laminated Composites Containing a Hole

Abstract:

A progressive damage and failure model for fiber reinforced laminated composites is developed in combination of finite element procedure and micromechanical model based on a unit cell. The micromechanical model can be used to evaluate failure criteria at the micro-level with fiber and matrix material properties. Once either of the constituents has damaged, the corresponding material properties are degraded by the damage factor. The micromechanical model and the damage theory are implemented in the finite software ABAQUS by using the user material subroutine UMAT and VUMAT, to model the damage progression and compute the ultimate strength of the composite laminates containing a hole. The predicted strengths for this model is compared with the experimental results, and a well agreement in the simulation and experimental resulted is revealed.

• Periodical: Advanced Materials Research (Volumes 314-316)
• Pages: 2243-2252
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.314-316.2243
• Online since: August 2011
• Authors: Bo Ming Zhang, Lin Zhao
• Keywords: Composite, Failure Criteria, Finite Element Model (FEM), Micromechanics, Progressive Damage Analysis, User Material Subroutine

References

[1] Zhengming Huang: International Journal of Solids and Structures Vol.38 (2001), pp.4147-4172 (In Chinese)

[2] Ireneusz Lapczyk, Juan A. Hurtado: Composites: Part A Vol.38 (2007), pp.2333-2341

[3] Yuequan Wang, Mingbo Tong and Shuhua Zhu: Acta Materiae Compositae Sinica Vol.26 (2009), pp.159-166 (In Chinese)

[4] Guofu Lu, Yong Liu and Chenglin Zhang: Journal of Nanjing University of Aeronautics & Astronautics Vol.41 (2009), pp.41-47 (In Chinese)

[5] Linde P, Pleitner J and Boer H: ABAQUS Users' Conference 2004, pp.421-439.

[6] J.Aboudi: Compos. Sci. Technol Vol.33 (1988), pp.79-96.

[7] Y. W. Kwon, J. M. Berner: Engineering Fracture Mechanics Vol.52 (1995), pp.231-242

[8] Y. W. Kwon, J. M. Berner: Compuyers & Structures Vol.64 (1997), pp.375-382

[9] Rami Haj-Ali, Hakan Kilic and Anastasia Muliana: Composites Science and Technology Vol.67 (2007), pp.1993-2004

[10] Evan J. Pineda, Anthony M. Waas and Brett A. Bednarcyk: Springer Science Vol.158 (2009), pp.125-143

[11] Evan J. Pineda, Anthony M. Waas and Brett A. Bednarcyk. 49th AIAA Structures, Structural Dynamics, and Materials Conference (2008), pp.1929-1952

[12] Boming Zhang, Zhong Yang and Yufeng Wu: Materials and Design Vol.31 (2010), pp.2312-2318 (In Chinese)

[13] Xiaohong Wang, Boming Zhang and Changxi Liu: Chinese Journal of Computational Mechanics Vol.26 (2009), pp.446-452 (In Chinese)

[14] Chang F K, Chang K Y: Journal of Composite Materials Vol.21 (1987), pp.834-855
