Analysis of Drinks Base Concentration Using Microprocessor Based Sensor

Abstract:

This paper presents an analysis of liquid drinks concentration using microprocessor based sensor. A prototype model based on hardware and software is used to run this analysis. The model then is tested and a few type of branded sold drinks base is analyzed on its concentration. The hardware comprises of a portable device that has been design to detect the differences between selected liquid drinks concentration. Those tested experimental drinks are Sunquick Blackcurrant, Sunquick Orange, Greenhill Rose, Greenhill Mango and Dutch Lady Full cream milk. A light dependant resistor (LDR) is used as the sensor to measure the light density through the liquid. The method has obtained the input voltage from the LDR circuit and display the concentration measurement on the liquid crystal display (LCD). Successful output has been gathered from the designing circuit. A printed circuit board (PCB) layout and programming using Basic language is developed and design in the identified hardware and software. This research has produced a data collections and statistical analysis on the identified drinks concentration. Comparison has been made and mathematical concept on the design system has been carried out.

• Periodical: Advanced Materials Research (Volumes 383-390)
• Pages: 5369-5374
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.383-390.5369
• Online since: November 2011
• Authors: Murizah Kassim, Ezril Hisham Mat Saad, Rosminah Mustakim
• Keywords: Liquid Concentration, Measured Technique, Microcontroller, Programming, Resistor, Sensor

References

[1] S. Yi and D. Jiexiong, Study on concentration measurement of small sample with optical fibers, " ICEMI , 09. 9th International Conference on, (2009).

[2] Puttmer and P. Hauptmann, Ultrasonic density sensor for liquids, Ultrasonics, Ferroelectrics and Frequency Control, IEEE Transactions on, vol. 47, pp.85-92, (2000).

DOI: 10.1109/58.818751

[3] K. J. Avdonkin and V. K. Makukha, The microprocessor CO concentration sensor based on heterostructure optopairs, in Electron Devices and Materials, 2005. Proceedings. 6th Annual, International Siberian Workshop and Tutorials on, (2005).

DOI: 10.1109/sibedm.2005.195612

[4] S. Doerner, T. Schultz, T. Schneider, K. Sundmacher and P. Hauptmann, Capacitive sensor for methanol concentration measurement in direct methanol fuel cells (DMFC), in Sensors, pp.639-641 vol. 2. 2004. Proceedings of IEEE, (2004).

DOI: 10.1109/icsens.2004.1426247

[5] M. C. Tomic and Z. V. Djinovic, Inline Liquid Concentration Measurement in Nanoliter Volume Using Fiber-Optic Low-Coherence Interferometry, Sensors Journal, IEEE, vol. 8, pp.587-592, (2008).

DOI: 10.1109/jsen.2008.918700

[6] K. Ikeda, Ultrasonic liquid-concentration sensor with temperature compensation, in Frequency Control Symposium, 1998. Proceedings of the 1998 IEEE International, pp.652-659, (1998).

DOI: 10.1109/freq.1998.717970

[7] S. Jie, C. Zhenyi, S. Yuqing and G. Qiang, Solution-concentration Sensor Using a Fused Fiber-optic Coupler, " in Electronic Measurement and Instruments, 2007. ICEMI , 07. 8th International Conference on pp.4-181, (2007).

DOI: 10.1109/icemi.2007.4351111

[8] Y. Yen-Liang, W. Cheng-Chi, J. Ming-Jyi, C. Chia-Hsun, T. Shih-Ming, L. Ten-Pin and C. Kuang-Sheng, Real-time measurement of glucose concentration using position sensing detector, in Nano/Micro Engineered and Molecular Systems, 2008. NEMS 2008. 3rd IEEE International Conference on pp.561-565, (2008).

DOI: 10.1109/nems.2008.4484395

[9] G. J. Grillo, J. C. Anton, F. Ferrero and M. A. Perez, Low-cost video-microscopy system for evaluation of fresh cow milk somatic cell concentration, in Instrumentation and Measurement Technology Conference, IMTC, Proceedings of the 18th IEEE, 2001, pp.906-909 vol. 2, (2001).

DOI: 10.1109/imtc.2001.928210

[10] D. Sparks, R. Smith, M. Straayer, J. Cripe, R. Schneider, S. Massoud-Ansari and N. Najafi, A microfluidic system for the measurement of chemical concentration and density, in Transducers, Solid-State Sensors, Actuators and Microsystems, 12th International Conference on, pp.300-303 vol. 1, (2003).

DOI: 10.1109/sensor.2003.1215312

[11] F. Ni, Set Pair Analysis for Rural Drinking Water Quality, in Bioinformatics and Biomedical Engineering (iCBBE), 2010 4th International Conference, pp.1-5, (2010).

DOI: 10.1109/icbbe.2010.5515095

[12] F. Ni, Grey Correlation Analysis between Liver Cancer and Drinking Water Quality in Southeastern Coastal Areas of China, in Management and Service Science (MASS), 2010 International Conference on pp.1-4., (2010).

DOI: 10.1109/icmss.2010.5577499
