Microstructure Characterization of White Layer Formed by Hard Turning and Wire Electric Discharge Machining in High Carbon Steel (AISI 52100)

Abstract:

White layers, formed during hard turning and wire electric discharge machining, were characterized by means of X-ray diffraction, scanning electron microscopy and transmission electron microscopy. Different cutting speeds and flank wear were utilized in order to obtain different thermally and/or plastically deformed white layer. Since the white layer after wire electric discharge machining is mainly thermally induced, it was used as a reference structure. In the investigation, both bainitic and martensitic structures were studied. With a constant flank wear of 0.175 mm the thickness of the white layer increased from 1.5 μm to 3 μm as the cutting speed was increased. In both processes the white layer were characterized by nanosized grains and surface tensile residual stresses. M₃C carbides were observed in the hard turned white layer, indicating that the time and temperature needed for completely dissolving the carbides were not reached during cutting. For both materials the white layers formed by wire electric discharge machining consisted of ~ 30 vol. % of retained austenite. Observation regarding the volume fraction of the retained austenite in the white layer formed by hard turning for martensitic material showed an increase in the volume fraction of retained austenite from ~ 2 - 3 vol. % to ~ 6 vol. %, while this observation was not seen in the white layer formed in the bainitic material.

• Periodical: Advanced Materials Research (Volume 409)
• Pages: 684-689
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.409.684
• Online since: November 2011
• Authors: S. B. Hosseini, Uta Klement, J. Kaminski
• Keywords: Hard Turning, TEM, White Layer, Wire Electric Discharge Machining (WEDM), X-Ray Diffraction (XRD)

References

[1] M. Field and J. F. Kahles: Annals of CIRP, Vol. 20, 2, (1971), pp.153-163.

[2] H. K. Tonshoff, C. Arendt, R. Ben Amor: Annals of the CIRP, Vol. 49, 2, (2000), pp.547-566.

[3] J. Rech, A. Moisan: INT J MACH TOOL MANU, Vol. 43, (2003), pp.543-550.

[4] S. Smith, S. N. Melkote, E. L. -Curzio, T. R. Watkins, L-. Allard, L. Riester: MATER SCI ENG A, Vol. 459 (2007), pp.337-346.

[5] F. Hashimoto, Y. B. Guo, A. W. Warren: Annals of CIRP, Vol. 55, 1, (2006).

[6] Y. B. Guo, J. Sahni: INT J MACH TOOL MANU, Vol. 44 (2004), pp.135-145.

[7] Y. B. Guo, A. W. Warren, F. Hashimoto: CIRP-JMST 2, (2010), pp.129-134.

[8] J. -P. Kruth, L. Stevens, L. Froyen, B. Lauwers: Annals of CIRP, Vol. 44, 1, (1995), pp.169-172.

DOI: 10.1016/s0007-8506(07)62299-9

[9] G. Cusanelli, A. Hessler-Wyser, F. Bobard, R. Demllayer, R. Perez, R. Flukiger: J MATER PROCESS TECH, Vol. 149, 2004, pp.289-295.

[10] B. Ekmekci: METALL MATER TRANS B, Vol. 40B, (2009), pp.70-81.

[11] B. J. Griffiths: J TRIBOL-T ASME, Vol. 109, (1987), pp.525-530.

[12] Y. K. Chou, C. J. Evans: INT J MACH TOOL MANU, Vol. 39, (1999), pp.1863-1881.

[13] J. Barry and G. Byrne: MAT SCI ENG A-STRUCT A 325, 2002, 356-364.

[14] S. H. Kang and D. E. Kim: MATER SCI TECH SER, Vol. 21, 7, (2005), pp.817-823.

[15] J. A. McGeough and H. Rasmussen: INT J MACH TOOL D R, Vol. 22, (1982), pp.333-339.

[16] A. Ramesh, S. N. Melkote, L. F. Allard, L. Riester, T. R. Watkins: MATER SCI ENG A, Vol. 390, (2005), pp.88-97.

[17] K. W. Andrews: J IRON STEEL I, vol. 184, (1955), pp.414-427.

[18] C. A. Stickels: METALL MATER TRANS, Vol. 5, (1974), pp.865-874.
