Electrical Characteristics and Microstructures of Dy-Doped Bi4Ti3O12 Ceramics

Article Preview

Abstract:

The electrical properties of Dy-bismuth titanate (Bi4-xDyxTi3O12) prepared by a conventional ceramic technique have been investigated. At applied d.c. field below 200V/mm, the current-voltage curve of Dy-doped sample exhibits a simple ohmic behavior. The impedance spectrum of Dy-doped sample indicates that consist of semiconducting grain and moderately insulating grain boundary regions. XRD, SEM and EPMA analyses reveal crystalline phase characterized by a Bi-layered perovskite structure of Bi4Ti3O12 and the distribution of every element is uniform. Dy-doped sample exhibit randomly oriented and plate-like morphology.
