The Research on Directional Elements of High-Voltage Line Protections Based on Zero-Sequence Reactance of Fault Components

Abstract:

Zero-sequence directional elements under a small voltage are studied and a new directional element based on zero-sequence reactance of fault components is presented. From analysis and simulations we have that when a forward fault or a reverse fault occurs, the zero-sequence reactance of a fault component will less or larger than the line zero-sequence reactance respectively. Therefore, the direction of a fault can be distinguished. The simulation results of EMTP show that the directional element based on zero-sequence reactance of fault components can identify forward and reverse faults accurately and it can satisfy requirements of relay protections for high-voltage lines.

• Periodical: Advanced Materials Research (Volumes 424-425)
• Pages: 511-515
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.424-425.511
• Online since: January 2012
• Authors: Xiao Hui Zeng, Yong Hui Chen, Hong Song
• Keywords: Directional Element, High-Voltage Line, Voltage Threshold, Zero-Sequence Reactance

References

[1] Hui Wang, Benteng He, Yiquan Li．Research of CVT's influence on zero-sequence (negative-sequence) direction protection．Relay, 2006, 34(9)：1-3.

[2] Jiale Suonan, Xianglai Meng， Yong Chen，et al．A Novel Zero Sequence Directional Element Based on Fault Type. Proceedings of the CSEE, 2007, 27(1): 25-30.

[3] Jiale Suonan， Bin Du， Liqiang Xu, et al． A Novel Direction Element Based on Transformer Neutral Zero Sequence Current. Automation of Electric Power Systems, 2009, 33(15): 72-77.

[4] Yiquan Li, Chi Zhang, Zhiyuan Huang, et al．A New Supplement Scheme of Zero Sequence Directional Pilot Relay Based on Positive Sequence Voltage Replacement. Automation of Electric PowerSystems, 2008, 32(19): 63-66.
