Multi-Level Block Information Extraction in Engineering Drawings Based on Depth-First Algorithm

Abstract:

The problem of multi-level block reference is analyzed for the process of information extraction in engineering drawings. And the relationship of reference blocks has been established. By using depth-first algorithm, the multi-level reference path of blocks and the parameter transformation can be searched. Based on the algorithm, an arithmetic flow is proposed. And the method of coordinate transformation of reference blocks is expounded. The new method has important significance for comprehensiveness and accuracy of information automatic extraction of engineering drawings which contains multi-level reference blocks.

• Periodical: Advanced Materials Research (Volumes 468-471)
• Pages: 2100-2103
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.468-471.2100
• Online since: February 2012
• Authors: Jia Yi Zhang, Long Fei Zhao, Yong Ping Hao
• Keywords: Depth-First Search, Engineering Drawings, Information Extraction, Reference Block

References

[1] Min Hu, Xioahong Jiang and Jiaoying Shi: Chinese Journal of computer aided design and computer graphics Vol. 12 (2000), p.777 (In Chinese)

[2] X. G. Wu, X. Li and X. Y. Zuo: Key Engineering Materials Vol. 392–394(2009), p.1006.

[3] Ying Hou, Yuanjun He and Zhigang Hu: Chinese Journal of computer engineering Vol. 29(2003), p.180. (In Chinese)

[4] B. S. Prabhu, S. Biswas and S. S. Pande: Computers in Industry Vol. 44(2001), p.79.

[5] Bin Qin, Chunping Yan and Fei Liu: Chinese Journal of computer engineering Vol. 35(2009), p.184. (In Chinese)
