Infrared Thermal Imaging of Power Grid Fault Information Acquisition System Based on GIS

Abstract:

nfrared temperature measurement technology is an important means that early detection of equipment external overheating fault and internal insulation fault, and advanced detection methods of power equipment condition monitoring.Infrared temperature measurement technology found the hidden dangers of electrical equipment heating of the external connection points, has been widely applied in power system. With comparing the original ant colony optimization, this paper presents an improved weighted Ant Colony Optimization path planning algorithm based on Infrared image acquisition noise reduction processing and combining WCDMA network transmission mode, and constitute a visual background management system with rural power network .The system could capture power equipment infrared images and reduction noise simply, send it to the background server through the 3G network, for artificial auxiliary to predicting grid failure, scientific planning repair inspection path with improved navigation algorithm, and improve the stability of the power grid operation.

• Periodical: Advanced Materials Research (Volumes 791-793)
• Pages: 1892-1896
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.791-793.1892
• Online since: September 2013
• Authors: Wei Gang Zheng, Zai Lin Piao, Dong Ming Tan, Zhe Yuan Wang
• Keywords: Ant Colony Optimization (ACO), Distribution Network, Infrared Image, Navigation Overhaul

References

[1] Hu Ping, Han Xing. Design of wireless real-time video monitoring system based on 3G[J]. Computer Engineering and Design, 2011, (12).

[2] Piao Zailin, Zhao Bin, Liu Na. Application of genetic algorithm to optimization to the maintenance schedule of rural power network[J]. Transactions of the CSAE, 2007(3).

[3] Wang Ruyi. Research of Infrared Image Segmentation for Power Equipmentin Substation [D]. XiAn University of Science and Technology, (2011).

[4] Wang Zhisheng, Qin Yinshan. Infrared Temperature Measuring System for Power Transmission Line Based on GPRS[J]. Modern Electronics Technique, 2011, (13).

[5] Yang Liuchun. Intelligent data acquisition system based on ARM designs[J]. Automation & Instrumentation, 2011, (01).

[6] Li Juan, Tang Lijun, Wen Yongjun. The Design Of Handy Data Acquisition System Based on ARM[J]. Microcomputer Information, 2008, (25).

[7] Feng Xinxin. Efficient Implementation of Dijkstra Algorithm in Embedded GIS[J]. Transactions of Beijing Institute of Technology, 2009, (10).

[8] Cheng Jianwei, Wang Xingchun, Li Xiangzhen. Path prediction based on Dijkstra algorithm. [J]. Science and Technology Information, 2009, (35).
