The Design of a Low Cost CANopen Slave Node Based on STC90C514RD

Abstract:

CANopen is a kind of higher layer protocol based on CAN, and it is widely used in industrial automation field, especially in distributed motion control systems. The paper presents an approach of realizing CANopen slave node. Microcontroller STC90C514RD is used as a core chip to design the control system; the design adopts CTM1050 as the CAN transceiver and uses SJA1000 as the CAN controller. And the system consists of a CANopen slave node, input module and output module. MicroCANopen, which is an open source protocol stack of CANopen, is transplanted to main controller so that the function of CANopen could be implemented. Moreover the experimental platform is built to test the design of the system. The results prove that the design is feasible and valid.

• Periodical: Advanced Materials Research (Volumes 791-793)
• Pages: 1905-1908
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.791-793.1905
• Online since: September 2013
• Authors: Zai Ping Chen, Chao Qiang Jia
• Keywords: CAN, CANopen, Communication, Slave Node

References

[1] CiA, CANopen: Application layer and communication profile, draft standard 301, Version 4. 02 [S]. (2002).

[2] Fukui, K, Okubo, S. TBM cutting forces with particular reference to cutter and tunnel diameters [C]/ISRM 2003-Technology Roadmap for Rock Mechanics，South African Institute of Mining and Metallurgy, (2003).

[3] Olaf Pfeiffer, Andrew Ayre and Christian Keydel. Embedded Networking with CAN and CANopen. RTC Books [M], 2003: 52-63.

[4] Aibing Ye, Huayao Zheng, The Design and Implementation of CANopen Protocol Intelligent Analysis System" [C] WiCom , 09. 5th International Conference on Wireless Communications, Networking and Mobile Computing, 24-26 Sept. 2009: 1-4.

DOI: 10.1109/wicom.2009.5302339

[5] Schneider, Inc. CANopen Protocol Reference Guide [M]. (1996).

[6] STC MCU Limted, STC90C51RC/RD+series MCU STC90LE51RC/RD+series MCU datasheet [M]. (2011).
