Noise Analysis and Characterization of a CMOS Interface Circuit for Fluxgate Sensor

Abstract:

In this paper, noise analysis and characterization of a 5V CMOS interface circuit for the fluxgate is presented, which is based on second-harmonic detection of the output voltage. The circuit consists of oscillator, band pass filter, phase sensitive demodulation, low pass filter. The chip is fabricated in the 0.5μm two–metal and two-poly n-well CMOS process with an area of 4 mm2. Experimental results shows, the system exhibits a sensitivity of 16.5μV/nT for a magnetic field range of ±90μT in open-loop with 5kHz excitation frequency. Using 5V supply voltage, the power consumption of the system is measured to be 35 mW.

• Periodical: Advanced Materials Research (Volume 981)
• Pages: 107-110
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.981.107
• Online since: July 2014
• Authors: Chang Chun Dong*, Zhan Peng Jiang
• Keywords: CMOS, Fluxgate Sensor, Interface Circuit

References

[1] L. D. Rienzo, R. Bazzocchi, and A. Manara, IEEE Trans. Instrum. Meas., 50, 1093(2001).

[2] A. Baschirotto, A. Cabrini, E. Dallago, P. Malcovati, M. Marchesi, and G. Venchi, IEEE Sensors J., 6, 365(2006).

DOI: 10.1109/jsen.2005.859778

[3] X. Qian, X. Li, Y. Ping, and J. Fan, IEEE Trans. Magn. 41, 3715(2005).

[4] C. C. Dong, W. P. Chen and Z. P. Zhou, Opt Precision Eng., 17, 1651 (2009).

[5] F. C. Williams and S. W. Noble, Proc. Inst. Elect. Engineers, 97, 445(1950).

[6] P. Ripka, J. Magn. Magn. Mater. 157, 427(1996).

[7] C. Hinnrichs, C. Pels, and M. Schilling, J. Appl. Phys. 87, 7085(2000).

[8] R. H. Kocha) and J. R. Rozen, Appl. Phys. Lett. 78, 1897 (2001).

[9] P. D. Dimitropoulos, Int. J. Electron. 92, 499(2005).

[10] P. D. Dimitropoulos, Int. J. Electron. 92, 561(2005).

[11] J. Kubik and P. Ripka, Sens. Actuators, A 132, 236(2006).

[12] P. Ripka, and M. Janosek, IEEE Sens. J. 10, 108(2010).
