Design of a High Performance CMOS Bandgap Voltage Reference

Abstract:

Bandgap voltage reference, to provide a temperature and power supply insensitive output voltage, is a very important module in the analog integrated circuits and mixed-signal integrated circuits. In this paper, a high performance CMOS bandgap with low-power consumption has been designed. It can get the PTAT (Proportional to absolute temperature) current, and then get the reference voltage. Based on 0.35μm CMOS process, using HSPICE 2008 software for circuit simulation, the results showed that , when the temperature changes from -40 to 80 °C, the proposed circuit’s reference voltage achieve to 1.2V, temperature coefficient is 3.09ppm/°C. Adopt a series of measures, like ESD protection circuit, in layout design. The ultimately design through the DRC and LVS verification, and the final layout size is 700μm * 560μm.

• Periodical: Advanced Materials Research (Volume 981)
• Pages: 90-93
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.981.90
• Online since: July 2014
• Authors: Yang Guang*, Bin Yu, Huang Hai
• Keywords: Amplifier, Bandgap Reference, PSRR, Temperature Coefficient

References

[1] Tajalli A, Atarodi M, Khodaverdi A, et al. Proceedings of the 2004 International Symposium on Circuits and Systems. Montreal, 2004: 45~48.

[2] P.E. Allen and D.R. Holberg, CMOS Analog Circuit design-2nd Ed,., Oxford University Press, (2002).

[3] Behzad Razavi Design of analog CMOS integrated circuits,. McGraw–Hill; (2001).

[4] Najafizadeh L, Filanovsky L. Towards a sub-1V CMOS voltage reference, IEEE, 2004: 53-56J.

[5] Banba H, Shiga H, Umerawa A，et al．IEEE Journal of Solid-State Circuits, 1999, 34(5): 670~674.

[6] Lin Hong chin, Liang Chao-Jui. Proceedings of the 2005 IEEE International Symposium on Circuits and Systems. IEEE，2005.: 4253~4256.
