Study on Rock-Breaking Simulation and Experiment of Double Disc Cutter of TBM

Abstract:

In order to improve working efficiency of the tunneling process and extend working life of disc cutter, explore the impact of cutter spacing and loading for the cutter rock-breaking effect. With the theory of rock crushing, Based on the finite element analysis software ABAQUS, the process of disc cutter breaking rock is simulated, considering the adjacent cutters sequential constraints, then, to make sure two cutter space with the method of SE in experiment.The simulation results showed that the optimal cutter spacings were both about 80mm in the same loading and the sequentially loading, but the rock-breaking effect of sequentially loading is better than the same loading. The experimental data showed that the minimum specific energy of rock breaking is appeared cutter spacing between 80mm and 90mm. Thus, the correctness and rationality of the simulation was verified. The study is good for understanding the rock-breaking mechanism of double disc cutter and has a certain promoting value to optimize TBM cutter system.Keywords:TBM, rock fragmentation, ABAQUS, cutter spacing, sequentially cutting

• Periodical: International Journal of Engineering Research in Africa (Volume 23)
• Pages: 80-88
• DOI: https://doi.org/10.4028/www.scientific.net/JERA.23.80
• Online since: April 2016
• Authors: F. Lu, C. Zhang*, J. Sun, J.X. Tian, M. Liu, Y.H. Wu
• Keywords: ABAQUS, Cutter Spacing, Rock Fragmentation, Sequentially Cutting, TBM

References

[1] Xia Yimin, Wu Yuan, Guo Jincheng, Tian Yanchao, Lin Laikuang and Bian Zhangkuo, Numerical Study on the Breaking Mechanism of TBM Edge Cutter, Journal of China Coal Society, Vol. 39, No. 1, pp.172-178, (2014).

[2] Wu Yuhou, Sun Jian, Zhou Peng and Sun Hong, Study on the Adaptability of the Cutter to the Rock Properties of the Boring Machine, Journal of Shenyang Jianzhu University, Vol. 28, No. 1, pp.156-161, (2012).

[3] Song Kezhi, Yuan Dajun and Wang Mengshu, Review of Interaction on Disc Cutter and Rock, Journal of Railway Engineering Society. No. 6, pp.66-69, (2005).

[4] Wei Bin, Donghuantuo Mine Hard Rock Boring Machine in Mountain Application in Tunneling, Technology and Market, Vol. 20, No. 7, p.151, (2013).

[5] Xiangheng Zhu, Yimin Xia, Tao Ouyang and Kai Yang, Distribution Law of Excavating Load of TBM Disc Cutter and Cutterhead, Applied Mechanics and Materials, No. 4, pp.71-74, (2007).

DOI: 10.4028/www.scientific.net/amm.615.22

[6] van Empel WHNC and Kaalberg FJ, Advanced modeling of innovative bored tunnel design of Amsterdam North/Southline, Finite Elements in Civil Engineering Applications, p.313–323, (2002).

DOI: 10.1201/9781003211365-57

[7] Man Lintao and Li Shouju. Finite Element Numerical Simulation of the Process of Disc Cutter Breaking Rock, Engineering Construction. Vol. 43, No. 4, pp.1-5, (2011).

[8] Okan Su and Nuri Ali Akcin, Numerical Simulation of Rock Cutting Using the Discrete Element Method, International Journal of Rock Mechanics and Mining Science, No. 48, pp.434-442, (2011).

DOI: 10.1016/j.ijrmms.2010.08.012

[9] Cho J.W., Jeon S., Yu S.H. and Chang S.H., Optimum Spacing of TBM Disc Cutters: A Numerical S imulation Using the Three-Dimensional Dynamic Fracturing Method", Tunnelling and Underground Space Technology, Vol. 25, No. 3, pp.230-244, (2010).

DOI: 10.1016/j.tust.2009.11.007

[10] Zhang Ke, Wang Tengyue, Sun Hong, Wang He and Zhao Kaijun, Simulation of Disc Cutter Breaking Rock in Whole Section Rock, Journal of Shenyang Jianzhu University (Natural Science). Vol. 26 , No. 6, pp.1209-1213, (2010).

[11] Wu Yuhou, Zhang Jiannan, Wang He, Optimal Analysis for cutter space of linear cutter machine based on ABAQUS, Journal of Shenyang Jianzhu University, Vol. 28, No. 5, pp.928-931, (2012).

[12] Feng Huanhuan, Chen Kui, Zhou Jianjun, Li Fengyuan  and Wang Zhufeng, Analysis and Calculation of optimum TBM disc cutter spacing, Modern turnnelling technology, Vol. 51, No. 3, pp.124-130, (2014).

[13] Li Gang, Wang Wanshan, Study on optimum spacing of TBM disc cutter, Journal of Harbin Engineering University, Vol. 34, No. 7, pp.914-917, (2013).

[14] Wu Feng, Research and Design of TBM Disc and Structural Parameter Optimization of Cutter Penetration, Central South University. (2012).

[15] R. Gertsch, L. Gertsch and J. Rostami, Disc Cutting Tests in Colorado Red Granite: Implications for TBM Performance Prediction, International Journal of Rock Mechanics and Mining Sciences, Vol. 44, No. 2, pp.38-246, (2007).

DOI: 10.1016/j.ijrmms.2006.07.007
