Residual Stress Analysis of Epoxy Coating/Substrate System Using Curvature Measurement Method

Abstract:

The residual stresses in an epoxy film coated on Si wafer induced during polymerization at room temperature are investigated. The curvature measurement method and the boundary element method (BEM) are employed to investigate the residual stresses. An epoxy film is coated on a relatively thick Si wafer. The normal stress across thickness of the epoxy film is estimated from wafer curvature measurements to be 15- 20MPa . The boundary element method is employed to investigate the whole stresses in the film. The numerical result for the normal stress across thickness of the film, σ xx , shows good agreement with the experimental result obtained by using the curvature measurement method. The singular stress is observed near the interface corner. Such residual stresses are large enough to initiate interface delamination to relieve the residual stresses.

• Periodical: Key Engineering Materials (Volumes 345-346)
• Pages: 793-796
• DOI: https://doi.org/10.4028/www.scientific.net/KEM.345-346.793
• Online since: August 2007
• Authors: Sang Soon Lee, In Wook Jeon, Young Chol Chang
• Keywords: Boundary Element Method (BEM), Chemical Shrinkage, Curvature Measurement Method, Epoxy, Polymerization, Residual Stress

References

[1] G.G. Stoney : Proceedings of the Royal Society(London), A82(1909), p.172.

[2] S.P. Timoshenko : Journal of the Optical Society of America, Vol. 11(1925), p.233.

[3] L.B. Freund : Journal of the Mechanics and Physics of Solids, Vol. 48 (2000), p.1159.

[4] L.B. Freund and S. Suresh : Thin Film Materials (Cambridge, 2003).

[5] S.S. Lee and R.A. Westmann: Int. J. Numerical Methods in Engineering, Vol. 38(1995), p.607.

[6] J.T. Pan and I.A. Blech : Journal of Applied Physics, Vol. 55 (1984), p.2874.

[7] A.L. Shull and F. Spaepen : Journal of Applied Physics, Vol. 80 (1996)�.
