Improvement on Yield of Anisotropic Conductive Film Attach Process in TFT-LCD Module Using Taguchi Method

Abstract:

Anisotropic Conductive Film (ACF) is one of the important materials in LCM (Liquid Crystal Module) process, it is used in bonding process to make the driving circuit conductive. Because the price of TFT-LCD is much lower than before in recent years, the ACF cost has higher ratio in manufacture cost. The conventional long bar ACF attach unit is changed to short bar ACF attach unit in new bonding equipment. However, the new type machine was not optimized in process and mechanical design. Therefore, the failure rate of ACF attach process is much higher than the one of conventional method. This wastes the material and rework cost is also invisible. How to make the manufacturing cost down effectively and promote the product quality will be the important concern to keep the product competition. Therefore, the Taguchi method is used to analyze the problem. The ACF attach yield rate is selected to be objective function for optimization. By the optimization of quality characteristic using Taguchi method, the plasma clean speed, ACF peeling speed and ACF cutter spring setting are studied to optimize the design parameters.

• Periodical: Key Engineering Materials (Volume 443)
• Pages: 717-722
• DOI: https://doi.org/10.4028/www.scientific.net/KEM.443.717
• Online since: June 2010
• Authors: Jian Long Kuo, Kai Lun Chao, Chung Hao Hsieh
• Keywords: ACF, Plasma Clean, Taguchi Method, TFT-LCD

References

[1] Su Chaodun: Quality project, (Chinese Republic of China Quality Academic society, 2002).

[2] Li Huihuang: the Taguchi method-quality design's principle and the practice, (stand high, 2005).

[3] Luo Jinxing: Taguchi quality project direction, (Chinese production center of pressure, 1999) Ning-Cheng Lee, Reflow soldering process and troubleshooting: SMT, BGA, CSP and Flip Chip technologies.

DOI: 10.1108/mi.2003.21820aae.003

[4] Yang Zhengyu: Profit with the Taguchi method to improve the LCD manufacturing process, Feng Chia University, Industrial Engineering and Systems Management Institute, Master's thesis (2006).

[5] 2006 Hitachi chemical: Interconnection Technologies Using Anisotropic Conductive Adhesive Films For Output And Input Leads, (Aug. 10, 2004).

[6] Hitachi High-Technology: ACF attch NG improve report, (Oct. 1, 2007).

[7] Kuo-chau Liang: using plasma technology for clean process, Creating nano tech. Co., Ltd., (Apr. 13, 2004).

[8] Jia-ching Hsu: plasma setting and testing report, Chi-Mei Opto Co., Ltd., (July 29, 2008) ACF attach yield V. S throughputs.
