Analysing the Deformation Behaviour of Compacted Graphite Cast Irons Using Digital Image Correlation Techniques

Abstract:

During the last years the use of digital image correlation techniques (DIC) has become wide spread within different areas of research. One area in which these techniques are used is in the analysis of deformation of engineering materials. By the analysis of a set of successive images taken during a tensile test DIC makes it possible to determine how the deformation is localized. The observed local strains are often several times higher than the global strain measured by standard strain gauges. In this study, a set of compacted graphite cast irons (CGI) with different ratios of pearlite to ferrite have been examined by the use of DIC. In contrast to the normal use of DIC, where a pattern is sprayed on the tensile test sample as a reference for the determination of deformation taking place between successive images, the materials natural microstructural pattern has been used in this study. The use of the natural microstructural pattern makes it possible to study how the macroscopic deformation is accommodated within the different phases in the CGI studied. It is shown that the graphite phase accommodates a large portion of the strain and that the soft ferrite is strained more than the stronger, less ductile pearlite. The local strain of the observed area might be up to ten times higher than the global strain measured. The use of DIC improves the understanding of the deformation behaviour of compacted graphite cast irons and will be a useful tool when validating future finite element analyses of the micro-mechanical properties of cast irons.

• Periodical: Key Engineering Materials (Volume 457)
• Pages: 470-475
• DOI: https://doi.org/10.4028/www.scientific.net/KEM.457.470
• Online since: December 2010
• Authors: Torsten Sjögren, Per Eric Persson, Peter Vomacka
• Keywords: Cast Iron, CGI, Compacted Graphite, Deformation, DIC, Digital Image Correlation (DIC), Elastic, Ferrite, Graphite, Pearlite, Plastic, Strain Field

References

[1] H. T. Angus: Cast Iron: Physical and Engineering Properties, Butterworth & Co Ltd, London, (1976), p.62.

[2] R. C. Voigt, S. D. Holmgren: AFS Transactions Vol. 98 (1990), p.213.

[3] I. Svensson, T. Sjögren: International Journal of Metalcasting Vol. 3 (2009), p.67.

[4] T. Sjögren, I. L. Svensson: Metallurgical and Materials Transactions A: Physical Metallurgy and Materials Science Vol. 38 (2007), p.840.

[5] T. Sjögren, I. L. Svensson: International Journal of Cast Metals Research Vol. 18 (2005), p.249.

[6] T. Sjögren, I. L. Svensson: International Journal of Cast Metals Research Vol. 17 (2004), p.271.

[7] W. H. Peters, W. F. Ransom: Optical Engineering Vol. 21 (1982), p.427.

[8] F. M. Sánchez-Arévalo, G. Pulos: Materials Characterization Vol. 59 (2008), p.1572.

[9] P. Vomacka: Engine Technology International Vol. September (2009), p.62.

[10] EN ISO 6507-1: 2005 - Metallic materials - Vickers hardness test, European Committee for Standardization, (2006), p.1.

[11] ISO 16112: 2006(E) - Compacted (vermicular) graphite cast iron - Classification, ISO (the International Organisation for Standardization), (2006), p.1.
