Study of a Capacitive Clamped Beam RF MEMS Power Sensor Based on MEMS Technology

Abstract:

This paper proposes a sophisticated type of capacitive clamped beam RF MEMS power sensor, which is fabricated on GaAs substrate with MMIC technology. This new capacitive clamped beam RF MEMS power sensor can act quickly to the RF signals and consumes little power on central CPW line. A version of draft microwave circuit model is presented, in order to build a set of initial structure parameters of the clamped beam RF MEMS power sensor simulation model. The frequency scope of this designed clamped beam RF MEMS power sensor is from 8GHz to 12GHz. Through adjusting the set of initial structure parameters of simulation model, a set of successful and proper S parameter of HFSS simulation can be obtained, and the S parameter is: S11 is less than -35dB and S21 is less than 0.15dB. Based on the performance parameter mentioned, the optimization on the power sensor simulation structure has been presented.

• Periodical: Key Engineering Materials (Volume 483)
• Pages: 503-507
• DOI: https://doi.org/10.4028/www.scientific.net/KEM.483.503
• Online since: June 2011
• Authors: Zheng Zhu, Xiao Ping Liao, Di Hua
• Keywords: Capacitive, Clamped Beam, MMIC, Power Sensor, RF MEMS

References

[1] C. L. Goldsmith, Z. Yao, S. Eshelman and D. Denniston, Performances of low-loss RF MEMS capacitive switches, IEEE Microwave and Guided Wave Letters, vol. 8, n. 8, pp.269-271, August (1998).

DOI: 10.1109/75.704410

[2] C. L. Goldsmith, J. Randall, S. Eshelman, T. D. Lin, D. Denniston ,S. Chen and B. Norvell, Characteristics of micromachined switches at microwave frequencies, IEEE MTT-S Int. Microwave Symp. Dig., San Francisco, CA, June 1996, pp.1141-1144.

DOI: 10.1109/mwsym.1996.511231

[3] C. Chang and C. Peizen, Innovative micromachined microwave switch with very low insertion loss, Sensors and Actuators A: Physical, vol. 79, pp.71-75, (2000).

DOI: 10.1016/s0924-4247(99)00218-6

[4] J. P. Muldavin and G. M. Rebeiz, High-isolation CPW MEMS shunt switches-Part 2: Design, IEEE Trans. Microwave Theory Tech., vol. 48, no. 6, pp.1053-1056, June (2000).

DOI: 10.1109/22.904744

[5] J. Y. Park, H. K. Geun, K. W. Chung and J. U. Bu, Electroplated RF MEMS capacitive switches, Proc. of the IEEE Micro Electro Mechanical Systems (MEMS), 2000, pp.639-644.

DOI: 10.1109/memsys.2000.838593

[6] A capacitive RF power sensor basedon MEMS technology L J Fern'andez, R J Wiegerink, J Flokstra, J Ses'e, H V Jansen and M Elwenspoek.

[7] RF-MEMS Switches for Reconfigurable Integrated Circuits Elliott R. Brown, Senior Member, IEEE.

[8] RF theory, design and tehchnology. RF MEMS.

[9] Microwave Engineering, Third edition. David M. Pozar pp.138-159.
