Failure Behavior of PZT 95/5 under Direct Current, Pulsed Electric Field and Shock Compression

Abstract:

Failure behavior of PZT 95/5 under direct current, pulsed electric field and shock compression is studied by experimental and theory analysis in this paper. The electrothermal coupled failure behavior is a key mode when the PZT 95/5 is subjected to direct current. But when the pulsed electric field is applied to the PZT 95/5, the resonance effect and the relation between energy and frequency have been considered, the vibrant energy shifts to high frequency and the possibility of electromechanical-coupled failure behavior is increased with decreasing the pulsed duration. When the pulsed duration is increased, the failure behavior transfers from mechanical coupled with electric failure to direct current mode step by step. The Failure behavior of PZT 95/5 under compression is complex that not only all of failure mechanism in static must be considered but also the microstructure’s evolvement under shock compression should be considered.

• Periodical: Key Engineering Materials (Volumes 512-515)
• Pages: 1286-1290
• DOI: https://doi.org/10.4028/www.scientific.net/KEM.512-515.1286
• Online since: June 2012
• Authors: Fu Ping Zhang, Gao Min Liu, Jin Mei Du, Yu Sheng Liu, Yi Liu, Hong Liang He
• Keywords: Failure Behavior, PZT 95/5

References

[1] F.P. Zhang, J.M. Du, Y.S. Liu, H.L. He, Inspection of remanent polarization in the ferroelectric ceramic PZT 95/5 through pyroelectric effect, J. Am. Ceram. Soc. 90 (2007) 2639-2641.

DOI: 10.1111/j.1551-2916.2007.01760.x

[2] Y. Shindo, F. Narita, K. Horiguchi, et al., Electric fracture and polarization switching properties of piezoelectric ceramic PZT studied by the modified small punch test, Acta Materialia, 51 (2003) 4773-4782.

DOI: 10.1016/s1359-6454(03)00303-3

[3] S. Trolier-McKinstry and R. E. Newnham, Sensors, Actuators and Smart Materials, MRS Bull. 18 (1993) 27-33.

DOI: 10.1557/s0883769400037325

[4] K.D. McHenry and B.G. Koepke, Fracturemechanics of ceramics, in Fracture Mechanics of Ceramics, edited by R. C. Bradt, D. P. Hasselman, and F. F. Lange (Plenum, New York, 1983), Vol. 5, p.337–352.

[5] H. Cao and A. G. Evans, Electric field- induced fatigue crack growth in piezoelectrics, J. Am. Ceram. Soc. 77 (1994) 1783-1786.

DOI: 10.1111/j.1151-2916.1994.tb07051.x

[6] G. S. White, A. S. Raynes, M. D. Vaudin, and S. W. Freiman, Fracture behaviour of cyclically loaded PZT, J. Am. Ceram. Soc. 77 (1994) 2603-2608.

DOI: 10.1111/j.1151-2916.1994.tb04649.x

[7] T. Y. Zhang, J. E. Hack, Mode‐III cracks in piezoelectric materials, J. Appl. Phys. 71(1992), 5865-5870.

DOI: 10.1063/1.350483

[8] H. Wang and R. Singh, Crack propagation in piezoelectric ceramics: Effects of applied electric fields, J. Appl. Phys. 81 (1997) 7471-7479.

DOI: 10.1063/1.365290

[9] R E. Setchell, Shock wave compression of the ferroelectric ceramic Pb0.99(Zr0.95Ti0.05)0.98Nb0.02O3: Microstructural effects, J. Appl. Phys. 101 (2007) 053525-053534.
