Study on Measuring System of Automatic Image Alignment Refractive Index Based on New Mathematical Model

Abstract:

With the development of measuring technology,the measuring accuracy of optical glass refractive index of the increasingly high demand,V prism refractometers is major general instrument for measuring the refractive index of optical glass,not only the simple device,convenient measurement,and this method has high precision performance,however,the accuracy is only attained ,which in the regulation of national metrology verification and the introduction of V prism refractometers in the literature,the classic formula calculation principle formula error caused by refractive index has more than .Based on the mechanical structure and optical transmission to improve the original V prism refractometers the refractive index of air,by considering the influence on measurement precision of V prism refractometer,to mathematical modeling of V prism refractometer the principle formula,V can be measured refractive prism refractometer rate accuracy increased to ,measurement repeatability less than ,has important practical significance for realizing high accuracy measurement of the refractive index of optical glass.

• Periodical: Key Engineering Materials (Volumes 609-610)
• Pages: 1319-1323
• DOI: https://doi.org/10.4028/www.scientific.net/KEM.609-610.1319
• Online since: April 2014
• Authors: Qing Hua Yao*, Miao Cao, Chang Liu
• Keywords: Mathematical Models, Measuring System, Principle of Error, Refractive Index, V-Prism Refractometers

References

[1] HAO Peng-fei, ZHANG Xin-jun. Area CCD-Based High Accuracy Measurement Technology and Its Application [J], Journal of Tianjin University, 2008, Vol. 41 No. 12, 1443-1447.

[2] LIU Caiming. The evaluation of uncertainty in measurement of index of refraction of prism[J], JOURNAL OF ZHEJIANG UNIVERSITY(SCIENCES EDITION), 2000 27(1), 53-58.

[3] MENG Qinghua, XIANG Yang. Novel high accurate measurement method for refractive index of optical glass[J], Optics and Precision Engineering, 2008, 16(11): 2114-2119.

[4] ZHAO Mingfu HAN Xi. Response characteristics of refractive-index gradient based on long-period fiber gratings [J], Optics and Precision Engineering, 2013, No. 2, 316-322.

DOI: 10.3788/ope.20132102.0316

[5] T. Wei,Y. -K. Han,Y. -J. Li,H. L. Tsai,H. Xiao. Temperature-insensitive miniaturized fiber inline Fabry- Perot interferometer for highly sensitive refractive index measurement,. Optics Express. (2008).

DOI: 10.1364/oe.16.005764

[6] SUN Hui-gang, CHU Jiu-rong et al. Measurement of refractive index of plastic optical fibers. Optical Fiber Technology . (2001).
