Experimental Research on WEDM Machining for Metal Components with Micro/Meso-Scale

Abstract:

In order to meet the machining demand of the metal components with micro/meso-scale, a kind of micro-fabrication method is explored by Wire-cut Electric Discharge Machining (WEDM). To find solutions for the problems of machining, a series of WEDM experiments for the micro/meso-scale structure of a thin nickel plate are carried out based on the analysis of technology regularity of WEDM. Experimental results indicate that the reasonable constraint on the discharge energy is the key to finish the machining of the metal components with micro/meso-scale. The stable machining can be achieved by adjusting discharge parameters to lower levels. The micro/meso-scale machining defects of cantilever distortion and sharp corners bending can be solved by segmented and multiple cutting accordingly. At last, some examples of complex structures machined are shown.

• Periodical: Key Engineering Materials (Volumes 609-610)
• Pages: 1521-1525
• DOI: https://doi.org/10.4028/www.scientific.net/KEM.609-610.1521
• Online since: April 2014
• Authors: Man Cang Song*, Li Qun Du, Chong Liu, Jun Shan Liu, Ying Liu
• Keywords: Metal Components, Micro/Meso-Scale, Micromachining, Wire-Cut Electric Discharge Machining (WEDM)

References

[1] ZH. L. Wang, Micro manufacturing Technology, first ed., National Defense Industry Press, Beijing, 2005(in Chinese).

[2] P. M. Ming, Fundamental researching on UV-LIGA-Micro-EDM technology, Nanjing: Nanjing university of aeronautics and astronautics, 2006(in Chinese).

[3] R. L. Rong, Micro fabrication technology based on non-traditional machining, MW Metal Cutting. (13) (2011) 33-37(in Chinese).

[4] D. M. Cao, J. Jiang, R. Yang, et al., Fabrication of high-aspect-ratio micro-scale mold inserts by parallel μ-EDM, Microsyst. Technol. 12(9) (2006) 839-845.

DOI: 10.1007/s00542-006-0131-1

[5] L. Q. Du, SH. P. Mo, Y. SH. Zhang, et al, Fabrication of 3D metal microstructure based on UV-LIGA and micro-EDM technology, Opt. Precision Eng. 18(2) (2010) 363-368(in Chinese).

[6] P. S. Kodalagara, Material removal characteristics of micro-slot(kerf) geometry in μ-WEDM on aluminum, Int. Adv. Manuf. Technal. (51) (2010) 611-626.

DOI: 10.1007/s00170-010-2645-z

[7] S. C. Di, X. Y. Chu, D. B. Wei, et al, Analysis of kerf width in micro-WEDM, Int. J. Machine Tools & Manuf. (49) (2009) 788-792.

DOI: 10.1016/j.ijmachtools.2009.04.006

[8] O. Dodun, A. M. Goncalves, Using wire electrical discharge machining for improve corner cutting accuracy of thin parts, Int. Adv. Manuf. Technol. (41) (2009) 858-864.

DOI: 10.1007/s00170-008-1531-4

[9] Z. H. Zhang, L. B. Guo, H. Cui, et al, Surface texture evaluation of micro-WEDM, Applied Mechanics and Materials. (138-139) (2012) 1251-1257.

DOI: 10.4028/www.scientific.net/amm.138-139.1251

[10] J. ZH. Liang, Q. H. Liang, Multri-chip cutting for the thin workpiece using WEDM, Mechanical Engineer. (7)(2012) 122-123(in Chinese).

[11] W. CH. Qi, CH. P. Ma, J. Q. Gao, Research for the strategy of first cutting parameter optimization based on multiple cutting process, Electro-machining & mould. (3) (2012) 50-53(in Chinese).

[12] M. C. Song, T. L. Xie, L. Q. Du, et al., WEDM of meso-scale structure on thin nickel plate, Opt. Precision Eng. 21(7) (2013) 1748-1754 (in Chinese).
