Heat Transfer Characteristic of Flat Trapezoid Grooved Micro Heat Pipes

Abstract:

To study the heat transfer performance of micro heat pipe, theoretical analysis of flat plate micro heat pipe with trapezoid cross section are presented in this paper. A one-dimensional stationary mathematical model for micro heat pipe grooved capillary flow using finite volume method (FVM) was established. The micro heat pipe had vapor space connect with each other and the influences of shear stress between vapor and fluid in the working process were described in the model which made the model more precisely. The axial variation of working fluid distribution in the heat pipe, pressure difference between vapor and liquid, and velocity of vapor and liquid were analyzed. In addition, the maximum heat transport capacity of micro heat pipe was calculated. The simulation results showed good agreement with the experiment results, and it could predict the heat transfer performance accurately, which was useful to micro heat pipe structural design.

• Periodical: Key Engineering Materials (Volumes 609-610)
• Pages: 1526-1531
• DOI: https://doi.org/10.4028/www.scientific.net/KEM.609-610.1526
• Online since: April 2014
• Authors: Yan Xia Yang, Xiao Dong Wang*, Yi Luo, Liang Liang Zou
• Keywords: Flat Plate Micro Heat Pipe, Numeral Model, Theoretical Analysis

References

[1] A. M. Abanbda, Novel vapor chamber heat spreader for thermal management of high power light emitting diodes, D. Degree Paper of North China Electric Power University, March (2012).

[2] R. Ram, Y. M Jayathi, V. G. Suresh, et al, A numerical model for transport in flat heat pipes considering wick microstrucre effects, J. International Journal of Heat and Mass Transfer. 54 (2011) 153-168.

DOI: 10.1016/j.ijheatmasstransfer.2010.09.057

[3] Tang Yong, Hu Zhonghai, Qing Jianbo, et al, Experimental investigation on isothermal performance of the micro-grooved heat pipe, J. Experimental Thermal and Fluid Science. 47 (2013) 143-149.

DOI: 10.1016/j.expthermflusci.2013.01.009

[4] J.C. Hsieh, H.J. Huang, S.C. Shen, Experimental study of microrectangular groove structure covered with multi mesh layers on performance of flat plate heat pipe for LED lighting module, J. Microelectronics Reliability. 52 (2012) 1071-1079.

DOI: 10.1016/j.microrel.2011.11.016

[5] P. Nandy, Yanuar, N. I. Ferdiansyah, Application of nanofluids to a heat pipe liquid-block and the thermoelectric cooling of electronic equipment, J. Experimental Thermal and Fluid Science. 36 (2011) 1-8.

DOI: 10.1016/j.expthermflusci.2011.04.015

[6] Yuan Wuhan, Zhao Jiyun, C.P. Tso, et al, Numerical simulation of the thermal hydraulic performance of a plate pin fin heat sink, J. 48 (2012) 81-88.

DOI: 10.1016/j.applthermaleng.2012.04.029

[7] R. Meysam, H. Pascal, Two-phase simulations of micro heat pipes, J. Computers and Fluids. 39 (2010) 451-460.

DOI: 10.1016/j.compfluid.2009.09.014

[8] Liu Xiangdong, Chen Yongping, Transient thermal performance analysis of micro heat pipes, J. Applied Thermal Engineering. 58 (2013) 585-593.

DOI: 10.1016/j.applthermaleng.2013.04.025

[9] Liu Yibing, Liu Huiying, Xiao Hongzhi, The numerical simulation on heat transfer performance of rectangular micro channel plate heat pipe, J. Refrigeration. 3 (2009) 40-44.

[10] Kou Zhihai, Bai Minli, Yang Hongwu, et al, Numerical and experimental investigation on flat heat pipes with integral micro-grooved wicks, J. Proceeding of the CSEE. 32 (2012) 92-00.

[11] Xu Lei, Theoretical research on micro flat heat pipe with silicon on glass structure, D. Degree Paper of Harbin Institute of Technology, June (2008).
