Control System of an Electromagnetic Vibrating Ring Gyroscope

Abstract:

Presented is a control system that is designed for an electromagnetic vibrating ring gyroscope. Three functions are realized in this control system. First, fixed amplitude of the drive-mode is guaranteed by using a variable gain control (VGC). Test result shows that the stability of the drive-mode amplitude is about 0.4% in the range of-40°C~80°C. Second, suitable drive-frequency is set up. And experimental result indicates that the suitable drive-frequency should be set between the drive-and sense-mode resonance frequencies, which results in a superior sensitivity. Third, regulation module is employed to further improve the performance.

• Periodical: Key Engineering Materials (Volumes 609-610)
• Pages: 952-956
• DOI: https://doi.org/10.4028/www.scientific.net/KEM.609-610.952
• Online since: April 2014
• Authors: Ji Li Liu, De Yong Chen*, Jun Bo Wang
• Keywords: Amplitude Stability, Control System, Drive Frequency, Electrode Trimming, Electromagnetic Vibrating Ring Gyroscope

References

[1] M.W. Putty. A micro-machined vibrating ring gyroscope. PHD thesis. Univ. Michigan: M.W. Putty, (1995).

[2] Guohong He, Khalil Najafi. A single-crystal silicon vibrating ring gyroscope. Porc. 15th IEEE Int. Conf. Vegas, CA, 2002: 718-721.

DOI: 10.1109/memsys.2002.984371

[3] Farrokh Ayazi, Khalil Najafi, A HARPSS Polysilicon Vibrating Ring Gyroscope, VOL. 10, No. 2, JMEMS, June 2001, pp.169-179.

DOI: 10.1109/84.925732

[4] B.J. Gallacher, J. Hedley, J.S. Burdess. Electrostatic correction of structure imperfections present in a micro ring gyroscope, Journal of Microelectromechanical system, VOL. 14, No. 2, April (2005).

DOI: 10.1109/jmems.2004.839325

[5] Chen Li, Chen De-yong, Wang Jun-bo et al. High performance electromagnetic micro-machined ring vibration gyroscope. Optics and Precision Engineering, 2099, 17(8): 1915-(1921).

[6] Chen Li, Chen De-yong, Wang Jun-bo. A novel micro-machined vibrating ring gyroscope. Optics and Precision Engineering, 2009, Vol. 17(6).

[7] Li Chen, Deyong Chen, Junbo Wang. The design and analysis of a robust micro-machined vibrating ring gyroscope. Proceeding of SPIE, 2008, Vol. 7159, (71590D): 1-8.

DOI: 10.1109/nems.2010.5767140

[8] Yang Bo, Zhou Bailing, Wang Shourong. Quadrature error and offset error suppression circuitry for silicon micro-gyroscope. Journal of Southeast University. Vol. 24, No. 4, pp.487-491.

DOI: 10.1109/nems.2008.4484364

[9] Wang Junbo, Shang Yanlong, Chen Deyong. Closed-loop Control of a SOI-MEMS Resonant Accelerometer with Electromagnetic Excitation. Nanotechnology and Precision Engineering, 2012, Vol. 4(3): 322-326.

DOI: 10.4028/www.scientific.net/kem.503.211

[10] Z.X. Hu, B.J. Gallacher, J.S. Burdess, C.P. Fell and K. Townsend, Precision Mode Matching of MEMS Gyroscope by Feedback Control, IEEE Sensors 2011 Conference, Limerick, Ireland, October 28-31, 2011, pp.16-19.

DOI: 10.1109/icsens.2011.6126998

[11] Luo Bing, Zhang Hui, Wu Mei-ping. Quadrature signal of microgyroscope and its effect on signal detection. Journal of Chinese Inertial Technology. VoL. 17 No. 5 Oct. (2009).

[12] Jili Liu, Deyong Chen, Junbo Wang. Regulating parameters of electromagnetic micro-machined vibrating ring gyroscope by feedback control [J]. Micro & Nano Letters, 2012, Vol. 7, Iss. 12, pp.1234-1236.

DOI: 10.1049/mnl.2012.0550
