Numerical and Experimental Investigation of Deep Drawing of Sandwich Panels

Abstract:

Commonly investigated problem on composite fabrication and forming for weight reduction in transportation and aerospace area is not completely cleared. The main difficulties on composites forming without building any defects caused new ways on process characterization due to the key parameters. In the paper two main problems were investigated, i.e. material fracture and material thinning during deep drawing. Through mechanical tests and numerical simulation the authors tried to couple the fracture with the technological boundary conditions of the deep drawing process and form a housing test part from a three-layer material.

• Periodical: Key Engineering Materials (Volumes 611-612)
• Pages: 1627-1636
• DOI: https://doi.org/10.4028/www.scientific.net/KEM.611-612.1627
• Online since: May 2014
• Authors: Sergey A. Tipalin, Michael A. Petrov*, Boris Saprikin, Nikolay Kosatchyov, Nikolay Shpunkin, Pavel A. Petrov
• Keywords: Autoform, Deep Drawing, Erichsen Test, Fracture, Mechanical Torsion Test, Multilayer Material, Numerical Simulation, Sandwich Plates, Stampack

References

[1] S.A. Tipalin, B.J. Saprikin, N.F. Shpunkin, A short review of the multilayer deformable materials for acoustical insulation, Izvestiya MSTU MAMI, №2 (2) (2012) 194 - 199 (in Russian).

DOI: 10.17816/2074-0530-68506

[2] S.A. Tipalin, V.I. Gladkov, A.I. Vlasov, M.Y. Nikitin, Numerical simulation of the valve cover construction based on the adhesive bonded joint, Izvestiya MSTU MAMI, №1 (5) 2008 201 - 206 (in Russian).

DOI: 10.17816/2074-0530-69732

[3] S.P. Yakovlev, S.S. Yakovlev, V.N. Chudin, Ya. A. Sobolev, Isothermal forming processes for multilayered constructions, in: Proceedings of the 3rd scientific-technical conference Physics of metals, material mechanic, nanostructures and forming processes - Metaldeform 2009, Samara, 2009, pp.296-302.

[4] V.I. Postnov, I.A. Kazakov, M.V. Postnova, Metallic-polymere materials in aircraft, in: Progressive technologies, materials and constructions, Ulyanovsk, 1999, pp.119-124 (in Russian).

[5] M.B. Zhukov, Investigation of the production processes for aeronautics by the complex operation of bending of sheets and profiles with additional loading, PhD-thesis, Moscow, 2003 (in Russian).

[6] Information on www. plasticsouz. ru.

[7] Information on www. antiphon. se.

[8] V.M. Malkov, Mechanics of the multilayer materials with elastomeres, Sankt Petersburg University, 1998 (in Russian).

[9] S. Tipalin, M. Nikitin, N. Schpunkin. Experimental study of V-bending process of steel-polymer-steel sheets at room temperature, Computer Methods in Materials Science № 3 (8) (2008) 138 - 143.

[10] S.A. Tipalin, N.F. Shpunkin, M.Y. Nikitin, A.V. Tipalina, Experimantel investigation of mechanical properties of insulation material, Izvestiya MSTU MAMI, №1 (2010) 166-170 (in Russian).

DOI: 10.17816/2074-0530-69680

[11] N.F. Shpunkin, S.A. Tipalin, M.Y. Nikitin, Sheet materials for vibration insulation in car bodies. Properties by shear deformation, Automotive industry №10 (2010) 39 - 40 (in Russian).

[12] S.A. Tipalin, N.F. Shpunkin, N.V. Kosatchyov, To the deformation distribution by axysymmetrical forming of the multilayer material, Izvestiya MSTU MAMI, №2 (2) (2013) 58 - 62 (in Russian).

[13] N.F. Shpunkin, S.A. Tipalin, M.Y. Nikitin, Patent RU 2431128 (2011).

[14] N.F. Shpunkin, S.A. Tipalin, Investigation of the properties of multilayer materials, Blank production in mechanical engineering №1 (2013) 28 - 31 (in Russian).

[15] M. Petrov, S. Tipalin, J. Bast, P. Petrov, N. Kosatschjov, S. Guk. Umformen eines Verbundwerkstoffs aus Stahlblechen, Kondtruktion VDI. Ingenieur-Werkstoffe 7/8 (2012) 5 - 7 (in German).

DOI: 10.1365/s35725-012-0023-5

[16] M. Petrov, Guk S., Petrov P., Bast J., Kosatschjov N., Tipalin S., Kraft- und Deformationscharakteristika beim Umformen eines Stahlblech-Verbundwerkstoffs, Lightweightdesign 5 (2012) 50 – 57 (in German).

DOI: 10.1365/s35725-012-0023-5
