FEM Analysis for Tangible Component Production

Abstract:

In high temperature metal forming techniques, analysis of the material flow and deformation as well as wear distribution during forging are very important, because they are directly correlated to the quality of the final component and to the productivity and die life. In this paper a commercially available Finite Element Method based simulator, namely Transvalor Forge 2008^©, is used to numerically investigate on the effects of the various parameters on the mode of the failure of dies during hot forging. The exploration has the purpose to evaluate the possibility and related benefits of the advancement from a traditional hot forging process to a modern thixoforging one in the case study of steel-made steering pistons production. As a first step, the part related to the hot forging process is in detailed analyzed, in order to get an exhaustive description of the role of the different parameters. One step and two step solutions are proposed and discussed.

• Periodical: Key Engineering Materials (Volumes 611-612)
• Pages: 1657-1664
• DOI: https://doi.org/10.4028/www.scientific.net/KEM.611-612.1657
• Online since: May 2014
• Authors: Mario Rosso*, Ildiko Peter
• Keywords: Finite Element Analysis (FEA), Hot Forging Process, Semi-Solid Process, Thixiforging

References

[1] Spencer D.B., Mehrabian R., Flemings M.C., Rheological behavior of Sn15 Pct Pb in the crystallization range. J. of Metal Trans. 3 (1972) 1925-(1932).

DOI: 10.1007/bf02642580

[2] Fraipont C., Leocomte-Beckers J., Influence of alloying elements on the thixoformability of a Chromium steel, Trans Tech Publications LTD, Zurich- The 10th International Conference on Semi-Solid Processing of Alloys and Components (2008) 523−527.

[3] S. Chayong, H.V. Atkinson, P. Kapranos, Multi-step induction heating regimes for thixoforming 7075 aluminium alloy, Mater. Sci. Technol. 20 (2004) 490-495.

DOI: 10.1179/026708304225012341

[4] Haga T., Kapranos P., Simple rheocasting processes, J. Mater. Proc. Tech. Vol. 130 – 131 (2002) 594-598.

DOI: 10.1016/s0924-0136(02)00819-1

[5] Nafisi S. And Ghomashchi R.,. Grain refining of conventional and semi-solid A356 Al–Si, Materials Characterization 57 (2006) 371-377.

DOI: 10.1016/j.matchar.2006.03.016

[6] Seo P.K., Kim D.U. and Kang C.G., The characteristics of grain size controlled microstructure and mechanical properties of Al-Si alloy by thixocasting and rheocasting process, J. Mater. Proc. Tech. 162 – 163 (2005) 570-578.

DOI: 10.1016/j.jmatprotec.2005.02.197

[7] Falak P. and Niroumand B., Rheocasting of an Al–Si alloy, Scripta Materialia 53 (2005) 53-60.

DOI: 10.1016/j.scriptamat.2005.03.017

[8] M. Rosso, I. Peter, R. Villa, 2008. Effects of T5 and T6 heat treatments applied to Rheocast A356 parts for automotive applications, J. Solid State Phenomena 141-143 (2008) 237-242.

DOI: 10.4028/www.scientific.net/ssp.141-143.237

[9] Hirt G., Shimahara H., Seidl I., Küthe F., Abel D., Schönbohm A. Semi-solid forging of 100Cr6 and X210CrW12 Steel, CIRP Annals – Manufacturing Technology 64 1 (2005) 257-260.

DOI: 10.1016/s0007-8506(07)60097-3

[10] Rassili A., Falzone S., Lecomte-Beckers J., Tooling Materials and Solutions for Thixoforming of Steel, Solid State Phenomena 192-193 (2008) 527-532.

DOI: 10.4028/www.scientific.net/ssp.192-193.527
