Development of a Tool Design Method in Cross Wedge Rolling: Description and Applications

Abstract:

Till now, the definition of cross wedge rolling dies requires know-how and important expertise from the designers. A decision-making methodology is being developed to provide sequential and logical steps to draw easier and faster the tool geometry. This methodology is based on designing rules found in literature that link the geometrical parameters of the desired rolled part and the geometrical parameters of the tool. Nevertheless, in the literature, the rules are not always consistent because the admissible domain for a parameter can differ from one author to another. In order to take into account this variability, a stability index is associated to each rule and to the designed tool. The methodology allows updating of the existing rules and the implementation of new rules. The set of parameters defining the geometry of the tool can be exported in the CAD/CAM software and FEM software. A case-study is presented to illustrate and validate the methodology.

• Periodical: Key Engineering Materials (Volumes 611-612)
• Pages: 1694-1701
• DOI: https://doi.org/10.4028/www.scientific.net/KEM.611-612.1694
• Online since: May 2014
• Authors: Catalina Gutierrez*, Philippe Mangin, Laurent Langlois, Régis Bigot
• Keywords: Cross Wedge Rolling, Tool Design Methodology

References

[1] Q. Li and M.R. Lovell, Cross wedge rolling failure mechanisms and industrial applications, International Journal of Advanced Manufacturing Technology, vol. 37 (2008) pp.265-278.

DOI: 10.1007/s00170-007-0979-y

[2] Q. Li, M.R. Lovell, W. Slaughter and T. Kaveh, Investigation of the morphology of internal defects in cross wedge rolling, Journal of Materials Processing Technology, no. 125–126 (2002) p.248–257.

DOI: 10.1016/s0924-0136(02)00303-5

[3] X.P. Fu and T.A. Dean, Past developments, current applications and trends in the cross wedge rolling process, International Journal of Machine Tools and Manufacture, vol. 33, no. 3 (June 1992) pp.367-400.

DOI: 10.1016/0890-6955(93)90047-x

[4] M. Hayama, Optimum Working Conditions In The Cross Rolling Of Stepped Shaft, Journal of Mechanical Working Technology, vol. 3 (1979) pp.31-46.

DOI: 10.1016/0378-3804(79)90030-5

[5] Neugebauer, Kolbe, and Riede, Sächsische Fachtagung Umformtechnik, in Optimierte verfahrensparameter und antriebskonzeptionen für das querwalzen, Chemnitz (1998) pp.1-25.

[6] Zb. Pater, W. Weronskia, J. Kazaneckib, and A. Gontarza, Study of the process stability of cross wedge rolling, Materials processing technology, vol. 92- 93 (1999) pp.458-462.

DOI: 10.1016/s0924-0136(99)00229-0

[7] W. Weronski and Zb. Pater, Selection of geometric parameters of transverse wedge rolling tools, Journal of materials processing technology, vol. 34 (1992) pp.273-280.

DOI: 10.1016/0924-0136(92)90117-b

[8] Umbach, Pannasch and Lorenz, Entwicklungsfortschritte zum Querwalzen von Stahlwerkstoffen, Umformtechnik, vol. 3 (1995) pp.173-175.

[9] Abramov, Preparation of input data for the numerical analysis of CWR process on the basis of the program-methodical complex Rolling, Advanced methods and technologies for materials manufacture and processing. Theory and Practice of Cross Wedge Rolling, vol. 4, (2008).

[10] P. Mangin, L. Langlois and R. Bigot, Development of cross wedge rolling process in France: Industry requirements and academic work in ENSAM, Metz.

[11] G. Holub, Příčné klínové válcování, SNTL, p.141 (1972) Czech.

[12] R Neugebauer, M. Kolbe and H. Riede, New warm forming processes to product hollow shafts, Journal of Materials Processing Technology, vol. 119 (2001) pp.277-282.

DOI: 10.1016/s0924-0136(01)00939-6

[13] Claasen, Herlan, and Lorenz, Sächsische Fachtagung Umformtechnik, in Querwalzen - Möglichkeiten und Kriterien, Freiberg (1995) p.16/1-16/34.

[14] X.P. Fu and T.A. Dean, Development of a knowledge-based sequence design system for cross wedge rolling, in Computers in engineering, Minneapolis (1994) pp.203-211.

DOI: 10.1115/cie1994-0402
