Error Separation and Dynamic Compensation Method in Coplanar Planar Grating Displacement Measurement System

Abstract:

To improve the measurement accuracy of two-dimensional (2D) precision working stages in the semiconductor manufacturing industry, an error separation and dynamic compensation method based on a planar grating is proposed for a 2D coplanar displacement measurement system. In the system, a planar grating of HEIDENHAIN PP281R is fixed in the center of precision working stage to build coplanar structure and reduce Abbe errors. And the system errors including grating period carved error, temperature effect, vibration effect and mount effect are modeled, calculated and separated. Then the separated errors are dynamically compensated from the corresponding displacement measurement results through data-processing software. Analysis results show that the proposed error separation and dynamic compensation method based on planar grating can improve the measurement accuracy of the coplanar displacement measurement system effectively.

• Periodical: Key Engineering Materials (Volume 613)
• Pages: 43-50
• DOI: https://doi.org/10.4028/www.scientific.net/KEM.613.43
• Online since: May 2014
• Authors: Yong Meng Liu*, Mao Qiang Yuan, Jie Ru Cao, Jing Ma, Jiu Bin Tan
• Keywords: Displacement Measurement, Dynamic Correction, Error Separation, Planar Grating, Two-Dimensional Working Stage

References

[1] X. C. Chu, H. B. Lü, S. H. Zhao, Research on long-range grating interferometry with nanometer resolution, Meas. Sci. Technol. 19(2008) 017001.

DOI: 10.1088/0957-0233/19/1/017001

[2] A. Kimura, W. Gao, Y. Arai, L. J. Zeng , Design and construction of a two-degree-of-freedom linear encoder for nanometric measurement of stage position and straightness, Precis. Eng. 34(2010)145-155.

DOI: 10.1016/j.precisioneng.2009.05.008

[3] W. X. Yu, Z. Q. Zou, X. T. Hu, Research on dynamic realtime error correction method in grating-based nanometrology, Chin. J. Sci. Instrum. 22(2001)63-64.

[4] X. Z. Wang, X. H. Dong, J. Guo, T. B. Xie, Two-dimension displacement sensing using a cross diffraction grating scheme, J. Opt. A- Pure and Appl. Op. 6(2004)106-111.

DOI: 10.1088/1464-4258/6/1/019

[5] H. J. Xia, Y. T. Fei, M. Zhang, Error analysis of 2-D diffraction grating interferometer for high-resolution displacement measurement, Proc. SPIE7130(2008)713052.

[6] L. Xi, X. F. Yu, W. Fan, Research on coplane structure of new nano-CMM two coordinate positioning platform, Ind. Meas. 17(2007)1-2.

[7] Z. Y. Shi, B. Zhang, Y. T. Fei, Re-visit to the Abbe principle, Chin. J. Sci. Instrum. 33 (2012) 1128-1133.

[8] K. C. Fan, B. H. Liao, Y. C. Chung, T. T. Chung, Displacement measurement of planar stage by diffraction planar encoder in nanometer resolution, IEEE Int. Instrum. Meas. Technol. Conf. (2012)894-897.

DOI: 10.1109/i2mtc.2012.6229209

[9] J. W. Cui, X. M. Liu, J. B. Tan, Self-calibration for 2D ultra-precision stage, Opt. Precis. Eng. 20(2012)1960-(1966).

[10] J. Ye, M. Takac, C. N. Berglund, An exact algorithm for self-calibration of precision metrology stages, Precis. Eng. 20(1997)16-32.

DOI: 10.1016/s0141-6359(97)00005-6
