Effect of Initial Thickness to Cut End Deformation of Hat Shape Channel Steel by Roll Forming

Abstract:

A hat channel, also called a furring channel, is a channel with a bottom horizontal web and two vertical flanges, as well as an outward lip that is fabricated by roll forming. When the channel is cut off at a specified length, the edge of the product will change due to the release of residual stress, and this change is generally called cut end deformation. The cut end deformation of channel steel was investigated via experiment and three-dimensional finite-element simulation. The effect of initial thickness on the cut end deformation of hat channel steel was studied. For hat channel steel, the deformations at the front end and back end increase when the sheet metal thickness increases. However, the influence of initial thickness on the cut end deformation of hat-shape channel steel is small.

• Periodical: Key Engineering Materials (Volumes 622-623)
• Pages: 1132-1138
• DOI: https://doi.org/10.4028/www.scientific.net/KEM.622-623.1132
• Online since: September 2014
• Authors: Siti Nadiah binti Mohd Saffe*, Nagamachi Takuo, Ona Hiroshi
• Keywords: Cut End Deformation, FEM Analysis, Hat Shape Channel Steel, Initial Thickness, Residual Stress, Roll Forming

References

[1] K. Kato, Y. Saito, Y. Nakawaki, and H. Kanno: Proc. 28th Japanese Joint Conference for the Technology of Plasticity, 1977, pp.357-359. (in Japanese).

[2] Y. Mihara, T. Suzuki, T. Kamata, and I. Yamanobe, NKK GIHO, 86, 1980, pp.287-293. (in Japanese).

[3] H. Ona, T. Jinba, J. Nakayama, and S. Matsuda: J. JSTP, 24-268 , 1983, 434-441. (in Japanese).

[4] George T. Halmos, Roll Forming Handbook, CRC press: Taylor & Francis Group, 2006, pp.5-20.

[5] T. Nagamachi, T. Nakako and D. Nakamura: Material Transactions, 54-10 (2013), 1910-(1915).

[6] Japan Society for Technology of Plasticity: Roll Forming (1990), 20, Corona Publishing.
