Temperature Measurement in the Rotary Forming Process of a Nickel Superalloys (INCONEL) Sheet during Induction Heating

Abstract:

The processes of spinning and flow forming of hard metal sheets made from nickel superalloy INCONEL can be realized cold or with heating - e.g. by a induction or laser. When metal sheet is heated it is necessary to measure the temperature field on heated area, because its determines the deformation susceptibility. To control the temperature field pyrometers and infrared cameras are used. Due to strong changes in the surface of a formed material, under temperature influence (oxidation) and the action of the forming rolls, it is necessary to determine the emissivity coefficient values as a function of temperature and surface conditions. The paper presents the concept of determining these values, as well as an alternative technique for measuring temperature field, based on the methods of image analysis.

• Periodical: Key Engineering Materials (Volumes 622-623)
• Pages: 823-830
• DOI: https://doi.org/10.4028/www.scientific.net/KEM.622-623.823
• Online since: September 2014
• Authors: Michał Kwiatkowski, Krzysztof Zaba, Maciej Nowosielski, Danel Pociecha, Tomasz Tokarski, Paweł Kita
• Keywords: Emissivity, Flow Forming, Induction Heating, Superalloys, Temperature Measurement

References

[1] C.C. Wong, T.A. Dean, J. Lin, A review of spinning, shear forming and flow forming processes, International Journal of Machine Tools & Manufacture 43 (2003) 1419–1435.

DOI: 10.1016/s0890-6955(03)00172-x

[2] O. Music, J.M. Allwood, K. Kawai, A review of the mechanics of metal spinning, Journal of Materials Processing Technology 210 (2010) 3–23.

DOI: 10.1016/j.jmatprotec.2009.08.021

[3] B.T. Araghi, A. Göttmann, G. Bergweiller, A. Saeed-Akbari, J. Bültmann, J. Zettler. M. Bambach, G. Hirt, Investigation on Incremental Sheet Forming combined with Laser Heating and Stretch Forming for the production of lightweight structures, Key Engineering Materials Vol. 473 (2011).

DOI: 10.4028/www.scientific.net/kem.473.919

[4] F. Klocke, T. Wehrmeister, Laser-Assisted Metal Spinning of Advanced Materials, Proceedings of the Second International WLT-Conference on Lasers in Manufacturing 2003 (2003).

[5] K. S. Lee, B. Hwangb, An approach to triangular induction heating in final precision forming of thick steel plates, Journal of Materials Processing Technology 214 (2014) 1008–1017.

DOI: 10.1016/j.jmatprotec.2013.11.002

[6] W. Minkina, Pomiary termowizyjne – przyrządy i metody, Wydawnictwa Politechniki Częstochowskiej, Częstochowa (2004).

[7] M. Sonka, V. Hlavac, R. Boyle, Image Processing, Analysis, and Machine Vision, second ed., Thomson-Engineering (1998).

[8] Information on http: /www. flir. com.

[9] Information on http: /www. raytek. com.

[10] Charakterystyka termometryczna termopar typu K ( NiCr-Ni ), Skala ITS-90, PN-EN 60584-1.

[11] Michał Jankowski, Elementy grafiki komputerowej, Wydawnictwa Naukowo-Techniczne (1990) ISBN 83-204-1326-5.
