Adsorption of Reactive Dyes Red 195, Blue 222, and Yellow 145 in Solution with Polyaniline-Chitosan Membrane Using Batch Reactor

Abstract:

The objective of this work was to investigate the characteristics of polyaniline-chitosan membrane by SEM, FTIR, tensile strength and percentage elongation and to determine the adsorption behavior of reactive dyes (Yellow 145, Red 195, Blue 222) onto the polyaniline-chitosan membrane. The removal of reactive dyes was investigated in a batch experiment. Parameters influencing the adsorption including pH (2-10), contact time (0-150 min), equilibrium study (30 min to 16 h) and initial concentration (10, 25, 50, 100, 250 and 500 mg×L^-1) were studied at room temperature. The dye concentrations were determined by a UV/VIS Spectrophotometer at the wavelengths 423, 540 and 620 nm for Yellow 145, Red 195 and Blue 222, respectively. The results indicated that the tensile strength and percentage elongation of polyaniline-chitosan membrane were 0.032 kN/mm² and 15.53%, respectively. It was found that optimum pH for adsorption of all dyes on polyaniline-chitosan membrane was pH 2. When the adsorption time increased, the adsorption efficiency increased accordingly. The adsorption equilibrium was found to be reached at 3 h in all adsorptions. Moreover, the isotherm study showed that the polyaniline-chitosan membrane adsorption corresponded to Freundlich model. Moreover, it was also found that polyaniline-chitosan membrane exhibits higher adsorption efficiency for reactive dyes than chitosan.

• Periodical: Key Engineering Materials (Volume 751)
• Pages: 713-718
• DOI: https://doi.org/10.4028/www.scientific.net/KEM.751.713
• Online since: August 2017
• Authors: Ratana Sananmuang*, Wipharat Chuachuad Chaiyasith, Kanokwan Wongjan
• Keywords: Adsorption, Chitosan, Polyaniline-Chitosan Membrane, Reactive Dye

References

[1] Z. Mbolekwa, C.A. Buckley, The removal of reactive dyes from dye liquor using activated carbon for reuse of salt, water and energy, Report to the Water Research Commission, 2008, 92 pages.

[2] T. Robinson, G. McMullan, R. Marchant, P. Nigam, Remediation of dyes in textile effluent: a critical review on current treatment technologies with a proposed alternative, Bioresour. Technol. 77 (2001) 247–55.

DOI: 10.1016/s0960-8524(00)00080-8

[3] M. -S. Chiou, P. -Y. Ho, H. -Y. Li, Adsorption of anionic dyes in acid solution using chemically cross-linked chitosan beads, Dyes Pigm. 60 (2004) 69-84.

DOI: 10.1016/s0143-7208(03)00140-2

[4] G. Gibbs, J.M. Tobin, E. Guibal, Influence of chitosan preprotonation on reactive black 5 adsorption isotherms and kinetics, Ind. Eng. Chem. Res. 43 (2004) 1–11.

DOI: 10.1021/ie030352p

[5] N. Sakkayawong, P. Thiravetyan, W. Nakbanpote, Adsorption mechanism of synthetic reactive dye wastewater by chitosan. J. Colloid. Int. Sci. 286 (2005) 36-42.

DOI: 10.1016/j.jcis.2005.01.020

[6] Y. Shimizu, S. Tanigawa, Y. Saito, T. Nakamura, Synthesis of chemically modified chitosans with a higher fatty acid glycidyl and their adsorption abilities for anionic and cationic dyes, J. Appl. Polym. Sci. 96 (2005) 2423–2428.

DOI: 10.1002/app.21707

[7] G. Crini, P. -M. Badot, Application of chitosan, a natural aminopolysaccharide, for dye removal from aqueous solutions by adsorption processes using batch studies: A review of recent literature, Prog. Polym. Sci. 33 (2008) 399-447.

DOI: 10.1016/j.progpolymsci.2007.11.001

[8] N. M. Kocherginsky, Z. Wang, Polyaniline membrane based potentiometric sensor for ascorbic acid, other redox active species and chloride, J. Electroanal. Chem. 611 (2007) 162-168.

DOI: 10.1016/j.jelechem.2007.08.012

[9] J. R. Evans, W. G. Davids, J. D. MacRae, A. Amirbahman, Kinetics of cadmium uptake by chitosan-based crab shells, Water Res. 36 (2002) 3219-3226.

DOI: 10.1016/s0043-1354(02)00044-1

[10] Information on http: /www. matweb. com/reference/tensilestrength. aspx. Accessed date Dec. 28, (2016).

[11] S. Ramanathan, V. Ponnuswamy, R. Mariappan, K. P. Nazeer, S.C. Murugavel, Physical investigations on chitosan graft polyaniline, Elixir Org. Chem. 43(2012) 6952-6954.

[12] A. Tiwari, S. K. Shukla, Chitosan-g-polyaniline: a creatine amidinohydrolase immobilization matrix for creatine biosensor, eXPRESS Polym. Lett. 3(2009) 553-559.

DOI: 10.3144/expresspolymlett.2009.69

[13] T. Thanpitcha, A. Sirivat, A. M. Jamieson, R. Rujiravanit, Preparation and characterization of polyaniline/chitosan blend film, Carbohydr. Polym. 64(2006) 560-568.

DOI: 10.1016/j.carbpol.2005.11.026

[14] J. H. Sung, H. J. Choi, M. S. Jhon, Electrorheological response of biocompatible chitosan particles in corn oil, Mater. Chem. Phys. 77(2002) 778-783.

DOI: 10.1016/s0254-0584(02)00167-0

[15] M. S. Chiou, G. S. Chuang, Competitive adsorption of dye metanil yellow and RB 15 in acid solution on chemically cross-linked chitosan beads. Chemosphere. 62(2006) 731-740.

DOI: 10.1016/j.chemosphere.2005.04.068

[16] H. Yoshida, A. Okamoto, T. Kataoka, Adsorption of acid dye on cross-linked chitosan fibers: equilibria, Chem. Eng. Sci. 48(1993) 2267-2272.

DOI: 10.1016/0009-2509(93)80242-i

[17] P. Fernandez-Saiz, M. J. Ocio, J. M. Lagaron, Antibacterial chitosan-based blends with ethylene-vinyl alcohol copolymer, Carbohydr. Polym. 80(2010) 874-884.

DOI: 10.1016/j.carbpol.2009.12.046
