The Effect of Surface on Conductivity of PbSnTe:In/BaF₂ Topological Crystalline Insulator in Space Charge Limited Current Regimes

Abstract:

The effect of surface chemical treatment on current-voltage (IV) characteristics of high-resistance MBE-grown PbSnTe:In films in space charge limited current (SCLC) regimes has been studied. At T=4.2 K depending on surface chemical treatment the current in films in SCLC regimes under no illumination could rise up to 10⁴ times and even more. The surface chemical treatment also affected both the value and behavior of the photocurrent. The qualitative model for the observed phenomena has been discussed.
