Influence of Tinning Material on Interfacial Microstructures and Mechanical Properties of Al12Sn4Si1Cu /Carbon Steel Bimetallic Castings for Bearing Applications

Abstract:

Fluxing and tinning processes are usually used to improve the adhesion of the Al bearing layer on steel substrate. Commonly after grinding the surface of the steel substrate, it is briefly immersed in flux solution followed by coating steel surface with either pure Sn (in a process known as tinning process) to promote adhesion between the bearing alloys and the steel. The current work is designated to investigate the influence of tinning material for carbon steel substrate using simultaneous fluxing and tinning mixture technique. The influence of three different tinning materials on the interface structure and shear strength of cast Al-Sn bearing alloy/steel bimetal composite is evaluated for compound casting technique. Sn pure, Sn-3Cu alloy and Sn-7.5Sb-3Cu powder alloys mixed individually with flux are used as tinning materials. It was found that using of different tinning materials have a significant effect on the bonding of interface area and the shear strength of interface as well. The shear strength of the bimetal fabricated using tinning mixture contains Sn+3% Cu with flux significantly increases by 59% compared to that fabricated using tinning mixture contains pure Sn. This increment is mainly due to the improvements of the interface bond structure and lower percentage of tin oxides. Such kind of phenomena can be explained in the fact that Cu minimizes the possibility of Sn oxidation during tinning process and during preheating of tinned steel substrate before casting of Al12Sn4Si1Cu bearing alloy as well.

• Periodical: Key Engineering Materials (Volume 835)
• Pages: 108-114
• DOI: https://doi.org/10.4028/www.scientific.net/KEM.835.108
• Online since: March 2020
• Authors: Mohamed Ramadan*, B. Ayadi, W. Rajhi, A.S. Alghamdi
• Keywords: Al-Sn, Bearing, Bimetal, Interface, Material, Microstructure, Tinning

References

[1] M. Ramadan, N. Fathy, K. S. Abdel Halim and A. S. Alghamdi, New trends and advances in bi-metal casting technologies, International Journal of Advanced and Applied Sciences. 6, 2, (2019) 75-80.

[2] J. Gawronski, J. Szajnar, P. Wróbel, Study on theoretical bases of receiving composite alloy layers on surface of cast steel castings, Journal of Materials Processing Technology. 157-158 (2004) 679-682.

DOI: 10.1016/j.jmatprotec.2004.07.153

[3] Z. Brytan, M. Bonek, L.A. Dobrzanski. Microstructure and properties of laser surface alloyed PM austenitic stainless steel, Journal of Achievements in Materials and Manufacturing Engineering. 1 (2010) 70-78.

[4] M. Cholewa, T. Wróbel, S. Tenerowicz, Bimetallic layer castings, Journal of Achievements in Materials and Manufacturing Engineering. 43: 1 (2010) 385-391.

[5] M. Ramadan, Interface characterization of bimetallic casting with a 304 stainless steel surface layer and a gray cast iron base, Advanced Materials Research. 1120-1121 (2015) 993-998.

DOI: 10.4028/www.scientific.net/amr.1120-1121.993

[6] G.C. Pratt, Bearing Materials: Plain Bearings, Encyclopedia of Materials: Science and Technology, (Second Edition)book, Elsevier . (2001).

[7] N. Fathy and M. Ramadan, Influence of volume ratio of liquid to solid and low pouring temperature on interface structure of cast Babbitt-steel bimetal composite, AIP Conference Proceedings 1966, 020028 (2018);.

DOI: 10.1063/1.5038707

[8] T. Wróbel, Bimetallic layered castings alloy steel–grey cast iron. Archives of Materials Science and Engineering, 48(2): (2011)118-125.

[9] J. Zhao, W. Zhao, S. Qu, Y. Zhang, Microstructures and mechanical properties of AZ91D/0Cr19Ni9 bimetal composite prepared by liquid−solid compound casting, Trans. Nonferrous Met. Soc. China 29(2019) 51−58.

DOI: 10.1016/s1003-6326(18)64914-3

[10] J. Shin, T. Kim, K. Lim, H. Cho, D. Yang, C. Jeong, S. Yi, Effects of steel type and sandblasting pretreatment on the solid-liquid compound casting characteristics of zinc-coated steel/aluminum bimetals, Journal of Alloys and Compounds. 778 (2019) 170-185.

DOI: 10.1016/j.jallcom.2018.11.134

[11] S. Cho, J. Yu, S. K. Kang, and D-Y Shih, Oxidation Study of Pure Tin and Its Alloys via Electrochemical Reduction Analysis, Journal of Electronic Materials. 34,5 (2005) 635-642.

DOI: 10.1007/s11664-005-0077-6

[12] N.A. Belov, T. K. Akopyan, I.S. Gershman, O.O. Stolyarova, A.O. Yakovleva, Effect of Si and Cu additions on the phase composition, microstructure and properties of Al-Sn alloys, Journal of Alloys and Compounds. 695 (2017) 2730-2739.

DOI: 10.1016/j.jallcom.2016.11.193
