Study on Coating Mechanism and Properties of Die CrN+DLC Layer

Abstract:

This paper introduces the principle of PACVD coating technology, technical characteristics, equipment composition and material characteristics of CrN+DLC. Taking H13 steel as the research object, its surface was treated with CrN+DLC. The microstructure, bonding state and hardness of the interface were studied by means of metallography, SEM, hardness and component distribution of the surface layer. The anti-crack ability and grade of DLC layer were analyzed by studying the shape of crack distribution with Rockwell hardness indentation, and the high quality layer with crack grade of HF1 was obtained. With the dual properties of diamond and graphite of DLC, it can make the die surface have lower friction coefficient, higher hardness, higher impact toughness, better solid lubrication performance and higher corrosion resistance. Surface DLC coating technology provides a new solution to improve the performance of the die.

• Periodical: Key Engineering Materials (Volume 905)
• Pages: 22-29
• DOI: https://doi.org/10.4028/www.scientific.net/KEM.905.22
• Online since: January 2022
• Authors: Li Jun Han*, Qing Wen Wu, Xue Song Wu, Ze Zhang, Hai Sheng Ma
• Keywords: CrN+DLC Layer, H13 Steel, Microstructure, PACVD Technology, Property, Surface Hardness

References

[1] C Wang, Brief Analysis on the Current Situation and Development Trend of Mold Technology in China, Construction Machinery. 2018, 509(07):16-18.

[2] B Sun, Heat Treatment and Surface Treatment Technology of Mold Steel, Metal Working (Hot Working). 2014(5):45-45.

[3] Y Li, L Wang, Research Progress of Ion Nitride Technology, Materials Review. 2014, 28(13):61-64.

[4] Oerlikon Balzers launches next generation of PPD™ technology as substitute to chrome-plating, Anti-Corrosion Methods and Materials. 2013, 60(3): 133-137.

DOI: 10.1108/acmm.2013.12860cab.007

[5] Fernández de Ara, J, Almandoz E, Palacio J F, Influence of temperature in arc-activated plasma nitriding of maraging steel in solution annealed and aged conditions, Surface and Coatings Technology. 2014, 258:754-762.

DOI: 10.1016/j.surfcoat.2014.07.084

[6] W Chen, J Zheng, Y Lin, Comparison of AlCrN and AlCrTiSiN coatings deposited on the surface of plasma nitrocarburized high carbon steels, Applied Surface Science. 2015, 332:525-532.

DOI: 10.1016/j.apsusc.2015.01.212

[7] T S Kumar, S, Comparison of TiAlN, AlCrN, and AlCrN/TiAlN coatings for cutting-tool applications , International Journal of Minerals, Metallurgy, and Materials. 2014, 21(8):796-805.

DOI: 10.1007/s12613-014-0973-y

[8] P P Cai, Study on PN-PVD Composite Treatment of H13 Steel Surface and Its Properties [D]. South China University of Technology, (2016).

[9] Q W Wu, Research on Microstructure and Properties of H13 Steel Surface by PPD+PVD Composite Treatment [D]. Jilin University, (2019).

[10] Y F Li, Preparation and Application of Novel Diamond-like Composite Films Doped with PVD Chromium [D].Shanghai University of Technology, (2016).

[11] W Zhu. Study on environmental tribological properties and electrochemical corrosion properties of diamond-like films [D].Southwest University, (2014).

[12] S S Lin, D Gao. Effect of Bias on Structure and Properties of DLC Film for High Power Pulsed Magnetron Sputtering, Materials Research and Application, 2020, 14(01): 1-8.
