Influence of Grooves Angle of Textured Ceramic Tools on the Final Roughness and Cutting Forces of Cold Work Tool Steel

Abstract:

Ceramic tools are a feasible solution for machining hard steels due to their excellent performance in high-temperature environments, which improves productivity. However, the high cutting speeds achieved with ceramic tools can generate cutting temperatures so high that they damage the surface roughness of the component. Therefore, this study aims to analyze the influence of different texturing inclinations on the final roughness of the component and the cutting forces during cutting on Al₂O₃ with TiC for the turning of 1.2990 cold work tool steel. The experimental setup involved testing five different texture grooves inclinations on the rake face of CNGA 120408 inserts, with a recommended cutting speed of 180 m/min, feed of 0.15 mm/rev, and a depth of cut of 0.5 mm. The tests were carried out in dry conditions. Results showed that the textured tools produced lower cutting forces (8%) and better surface roughness (improvement of 16% for R_a and 18% for R_z) than the reference tool without texture. Therefore, texturing inclinations can be used to mitigate the impact of high cutting speeds on the component during ceramic tool machining.

• Periodical: Key Engineering Materials (Volume 955)
• Pages: 81-88
• DOI: https://doi.org/10.4028/p-gH0GjS
• Online since: September 2023
• Authors: Pablo Fernández-Lucio*, Octavio Pereira Neto, Gorka Urbikain, Eneko Ukar, Luis Norberto López de Lacalle
• Keywords: Ceramic Tools, Cold Work Tool Steel, Hard Turning, Laser Engraving, Roughness, Textured Tools

References

[1] Bitterlich B, Bitsch S, Friederich K. SiAlON based ceramic cutting tools. J Eur Ceram Soc 2008; 28: 989–94.

DOI: 10.1016/j.jeurceramsoc.2007.09.003

[2] Sørby K, Vagnorius Z. High-Pressure Cooling in Turning of Inconel 625 with Ceramic Cutting Tools. Procedia CIRP 2018;77:74–7.

DOI: 10.1016/j.procir.2018.08.221

[3] Renz A, Khader I, Kailer A. Tribochemical wear of cutting-tool ceramics in sliding contact against a nickel-base alloy. J Eur Ceram Soc 2016;36:705–17.

DOI: 10.1016/j.jeurceramsoc.2015.10.032

[4] Zhuang K, Zhu D, Zhang X, Ding H. Notch wear prediction model in turning of Inconel 718 with ceramic tools considering the influence of work hardened layer. Wear 2014;313:63–74.

DOI: 10.1016/j.wear.2014.02.007

[5] Fernández-Lucio P, Pereira Neto O, Gómez-Escudero G, Amigo Fuertes FJ, Fernández Valdivielso A, López de Lacalle Marcaide LN. Roughing Milling with Ceramic Tools in Comparison with Sintered Carbide on Nickel-Based Alloys. Coatings 2021;11:734.

DOI: 10.3390/coatings11060734

[6] Dudzinski D, Devillez A, Moufki A, Larrouquère D, Zerrouki V, Vigneau J. A review of developments towards dry and high speed machining of Inconel 718 alloy. Int J Mach Tools Manuf 2004;44:439–56.

DOI: 10.1016/S0890-6955(03)00159-7

[7] Richards N, Aspinwall D. Use of ceramic tools for machining nickel based alloys. Int J Mach Tools Manuf 1989;29:575–88.

DOI: 10.1016/0890-6955(89)90072-2

[8] Xing Y, Deng J, Zhao J, Zhang G, Zhang K. Cutting performance and wear mechanism of nanoscale and microscale textured Al2O3/TiC ceramic tools in dry cutting of hardened steel. Int J Refract Metals Hard Mater 2014;43:46–58.

DOI: 10.1016/J.IJRMHM.2013.10.019

[9] Cui X, Guo Z, Guo J. Intermittent turning performance of ceramic tools with surface micro-geometry designed considering fluid-like behavior of chip. Ceram Int 2018;44:16890–9.

DOI: 10.1016/j.ceramint.2018.06.127

[10] Mishra SK, Ghosh S, Aravindan S. Performance of laser processed carbide tools for machining of Ti6Al4V alloys: A combined study on experimental and finite element analysis. Precis Eng 2019;56:370–85.

DOI: 10.1016/J.PRECISIONENG.2019.01.006

[11] Rajbongshi SK, Annebushan Singh M, Kumar Sarma D. A comparative study in machining of AISI D2 steel using textured and non-textured coated carbide tool at the flank face. J Manuf Process 2018;36:360–72.

DOI: 10.1016/j.jmapro.2018.10.041

[12] Standard I. ISO - ISO 4288:1996/Cor 1:1998 - Geometrical Product Specifications (GPS) — Surface texture: Profile method — Rules and procedures for the assessment of surface texture — Technical Corrigendum 1 n.d. https://www.iso.org/standard/29875.html (accessed June 15, 2021).

DOI: 10.3403/02337030

[13] Zhang K, Deng J, Ding Z, Guo X, Sun L. Improving dry machining performance of TiAlN hard-coated tools through combined technology of femtosecond laser-textures and WS2 soft-coatings. J Manuf Process 2017; 30: 492–501. https://doi.org/.

DOI: 10.1016/J.JMAPRO.2017.10.018
