The Role of Ceramic Materials in Surface Modification of Cutting Tools - A Review Paper

Abstract:

A modification cutting tool is a type of cutting tool that can be altered or adjusted to change its cutting properties. This can include changing the angle or shape of the cutting edge, adjusting the depth of cut, or modifying the material or coating used on the tool. These modifications allow for greater precision and efficiency in cutting operations, particularly in industries for manufacturing and construction different products. Ceramic materials can be used in coatings to provide a variety of benefits, such as corrosion, wear resistance , and thermal insulation. They also offer high hardness, low friction, and chemical stability. Ceramic coatings can be applied to various substrates including metals and ceramic. Modification of cutting tools using nanomaterial deposition is a promising approach to enhance their performance and durability. The process involves depositing one or more layer of nanosized particles onto the surface of the cutting tool, which can improve its mechanical, thermal, and tribological properties. Keywords: Ceramic materials ; coating ;cutting tools; coating process.

• Periodical: Key Engineering Materials (Volume 982)
• Pages: 131-146
• DOI: https://doi.org/10.4028/p-V9hXic
• Online since: July 2024
• Authors: Wurood Asaad*, Shaima'a J. Kareem, Haydar Al-Ethari
• Keywords: Ceramic Materials, Coating, Coating Process, Cutting Tools
