Extreme Environment Integrated Circuits Based on Enhancement Mode SiC JFETs

Abstract:

This paper presents results on developing high temperature capable SiC JFET based IC technology that can operate at temperatures up to 500 °C. All JFET devices are fully planar, formed by ion implantation, and the device design allows the use of semi-insulating or conductive SiC substrates. Basic analog and logic ICs were built in order to demonstrate the technology high temperature capability. All circuits used enhancement mode n-channel JFETs as active transistors, and depletion mode transistors as active loads. The logic circuits built included NOT, NAND, and NOR gates. The analog circuits built included a simple one-stage operational amplifier. JFETs and ICs were packaged in ceramic packages and tested at temperatures up to 500 °C.

You might also be interested in these eBooks

Silicon Carbide and Related Materials 2019

View Preview

Info:

Periodical:

Materials Science Forum (Volume 1004)

Pages:

1097-1103

DOI:

https://doi.org/10.4028/www.scientific.net/MSF.1004.1097

Citation:

Cite this paper

Online since:

July 2020

Authors:

Peter Alexandrov*, Matt O'Grady

Keywords:

High Temperature, Integrated Circuit (IC), JFET, SiC

Export:

RIS, BibTeX

Price:

Permissions CCC:

Request Permissions

Permissions PLS:

Request Permissions

Сopyright:

Citation:

* - Corresponding Author

References

[1] J. Korec, Silicon-on-insulator technology for high-temperature, smart-power applications, Materials Science and Engineering B, 29 (1995) 1.

DOI: 10.1016/0921-5107(94)04015-v

Google Scholar

[2] J. Eggermont, D. Ceuster, D. Flandre, B. Gentinne, P. Jespers, and J. Colinge, Design of SOI CMOS operational amplifiers for applications up to 300 °C, Proc. IEEE, 31 (1996) 179.

DOI: 10.1109/4.487994

Google Scholar

[3] P. Neudeck, S. Garverick, D. Spry, L. Chen, G. Beheim, M. Krasowski, M. Mehregany, Extreme temperature 6H-SiC JFET integrated circuit technology, Phys. Status Solidi A 206 (2009) 2329.

DOI: 10.1002/pssa.200925188

Google Scholar

[4] P. Neudeck et al., Prolonged 500 °C Operation of 6H-SiC JFET Integrated Circuitry, Materials Science Forum, 615-617 (2009) 929.

DOI: 10.4028/www.scientific.net/msf.615-617.929

Google Scholar

[5] P. Neudeck, D. Spry, M. Krasowski, N. Prokop, G. Beheim, Yearlong 500 °C Operational Demonstration of Up-scaled 4H-SiC JFET Integrated Circuits, IMAPS Int. Conf. High Temperature Electronics (2018) 71.

DOI: 10.4071/2380-4491-2018-hiten-000071

Google Scholar

[6] P. Alexandrov, M. O'Grady, N. Merrett, L. Walter, Analog and Logic High Temperature Integrated Circuits Based on Enhancement Mode Planar SiC JFETs, IMAPS Int. Conf. High Temperature Electronics (2018) 79.

DOI: 10.4071/2380-4491-2018-hiten-000079

Google Scholar

[7] PSPICE Reference Guide, 1985-2000 Cadence Design System.

Google Scholar
