Comparative Numerical Analysis of the Robustness of Si and SiC PiN Diodes Against Cosmic Radiation-Induced Failure

Abstract:

This work aims at extending the predictive simulation technique for cosmic ray-induced failure analysis from Si PiN diodes [1] to SiC PiN diodes. Accurate 3D cylindrical-symmetric transient simulations were performed with a minimum mesh size of 20nm at the center track of the impinging ion and a maximum time step of 0.1ps during the development of the ion-induced transient current. We made a comparative study between a SiC PiN diode and a Si PiN diode with the same blocking voltage of 1.5kV, using the same heavy ion transportation models. In the simulation, we observed different ion-induced current transients, differing not only in the peak value of the current, but also in its duration. Due to different physical mechanisms, the dependence of the ion-induced current on the reverse pre-bias voltage and the numerical mesh adaptations are also different. Eventually, we brieflydiscuss electro-thermal simulations, which indicate once more that the ion-induced transient current in the SiC PiN diodes under consideration is primarily drift current and involves only negligible impact ionization.

• Periodical: Materials Science Forum (Volume 1004)
• Pages: 1088-1096
• DOI: https://doi.org/10.4028/www.scientific.net/MSF.1004.1088
• Online since: July 2020
• Authors: Yaren Huang*, Benedikt Lechner, Gerhard Wachutka
• Keywords: Cosmic Radiation, PiN Diode, SEB, SiC, Single Event Burnout

References

[1] C. Weiß, Robustness of Silicon High Power Devices Against Cosmic Radiation­induced Fail­ ures., PhD diss., Technical University of Munich, (2015).

[2] S. Kuboyama, C. Kamezawa, N. Ikeda, T. Hirao and H. Ohyama, Anomalous Charge Collection in Silicon Carbide Schottky Barrier Diodes and Resulting Permanent Damage and Single­Event Burnout,, in IEEE Trans. on Nuclear Science, vol. 53, no. 6, p.3343­3348, Dec. (2006).

DOI: 10.1109/tns.2006.885165

[3] A. F. Witulski et al., Single­Event Burnout of SiC Junction Barrier Schottky Diode High­Voltage Power Devices,, in IEEE Trans. on Nuclear Science, vol. 65, no. 1, p.256­261, Jan. (2018).

[4] J. A. McPherson, etc., Heavy Ion Transport Modeling for Single­Event Burnout in SiC­Based Power Devices,, in IEEE Trans. on Nuclear Science, vol. 66, no. 1, p.474­481, Jan. (2019).

[5] A. Javanainen et al., Heavy­Ion­Induced Degradation in SiC Schottky Diodes: Incident Angle and Energy Deposition Dependence,, in IEEE Trans. on Nuclear Science, vol. 64, no. 8, p.2031­2037, Aug. (2017).

[6] A. M. Albadri, etc., Coupled Electro­Thermal Simulations of Single Event Burnout in Power Diodes,, in IEEE Trans. on Nuclear Science, 52, no. 6, p.2194­2199, (2005).

DOI: 10.1109/tns.2005.860691

[7] C. Abbate et al., Analysis of Heavy Ion Irradiation Induced Thermal Damage in SiC Schottky Diodes,, in IEEE Transactions on Nuclear Science, vol. 62, no. 1, p.202­209, Feb. (2015).

DOI: 10.1109/tns.2014.2387014

[8] C. Weiss, G. Wachutka, A Numerical "a­posteriori"­Method to Calculate Local Self­Heating in Power Devices After the Impact of a Cosmic Particle,; Proc. of SISPAD 2012, Denver, CO, USA, (2012).

[9] M. Lades. Modeling and Simulation of Wide Bandgap Semiconductor Devices: 4H/6H­SiC, PhD diss., Technical University of Munich, (2000).

[10] T. Ayalew SiC Semiconductor Devices, Technology, Modeling and Simulation, PhD diss., Technical University of Vienna, (2004).

[11] A. O. Konstantinov, O. Wahab, N. Nordell, U. Lindefelt, Ionization Rates and Critical Fields in 4H Silicon Carbide,, Applied Physics Letters, vol. 71, p.90­93, (1997).

DOI: 10.1063/1.119478

[12] B. Lechner, etc., Impact of Activation of Carbon Vacancies at High Temperatures on the Minor­ ity Carrier Lifetimes in the Intrinsic Area of 4H­SiC PiN Rectifier,, Proc. of the 12th ASDAM, Smolenice, Slovakia, (2018).

DOI: 10.1109/asdam.2018.8544472
