Crystal Separation Method of 6-Inch 4H-SiC Crystal Using Adhesion Shrinkage between a Seed and a Seed Holder in Cooling Process

Abstract:

6-inch 4H-SiC crystal ingot was successfully separated from a seed holder by the contraction enhancement of adhesive. The resin used as an adhesive with 10~30% in contraction ratio during the cooling was selected. The crack between seed holder and grown SiC crystal was observed to be formed after the cooling procedure and the crystal was easily separated from the seed holder without any machining process for the separation. The warp value and the rocking curve value of SiC crystal grown with modified adhesive was observed to be smaller than those of SiC crystal with conventional method.

You might also be interested in these eBooks

Silicon Carbide and Related Materials 2019

View Preview

Info:

Periodical:

Materials Science Forum (Volume 1004)

Pages:

26-31

DOI:

https://doi.org/10.4028/www.scientific.net/MSF.1004.26

Citation:

Cite this paper

Online since:

July 2020

Authors:

Jong Hwi Park, Byung Kyu Jang, Jung Woo Choi, Eunsu Yang, Jung Gyu Kim, Sang Ki Ko, Myung Ok Kyun, Kap Ryeol Ku, Dae Sung Kim, Won Jae Lee*

Keywords:

Adhesive Contraction, Crystal Quality, Crystal Separation, Warp

Export:

RIS, BibTeX

Price:

Permissions CCC:

Request Permissions

Permissions PLS:

Request Permissions

Сopyright:

Citation:

* - Corresponding Author

References

[1] Y. M. Tairov, V.F Tsevtkov, General principles of growing large-size single crystals of various silicon carbide polytypes, J. Crystal Growth. 52 (1981) 146-150.

DOI: 10.1016/0022-0248(81)90184-6

Google Scholar

[2] Y. Tupitsyn, A. Arjunan, R. T. Bondokov, R. M. Kennedy, T. S. Sudarshan, A Study of 6H-seeded 4H-SiC bulk growth by PVT, Mater. Sci. Forum. 483-485 (2005) 21-24.

DOI: 10.4028/www.scientific.net/msf.483-485.21

Google Scholar

[3] I. Manning, J. Zhang, B.Thomas, E. Sanchez, D. Hansen, D. Adams, G. Y. Chung, K. Moeggenborg, C. Parfeniuk, J. Quast, V. Torres, C. Whiteley , Large area 4H SiC products for power electronic devices, Mater. Sci. Forum. 858 (2016) 11-14.

DOI: 10.4028/www.scientific.net/msf.858.11

Google Scholar

[4] S. Nishino. Y. Kojima, J. Saraie, Springer proceeding in Physics, in: G. L. Harris, M. Spencer, C.Y.-W Yang (Eds.), Amorphous and Crystalline Silicon Carbide III, Springer-Verlang, New York, (1992).

DOI: 10.1007/978-3-642-84402-7_2

Google Scholar
