4H-SiC Power VDMOSFET Manufacturing Utilizing POCl₃ Post Oxidation Annealing

Abstract:

A novel POCl₃ post-oxidation annealing recipe was developed. The interface trap density (D_it) is extracted by the C-Ψ_S method close to conduction band edge. The performance of the POCl₃-treated oxide has been analyzed based on current density-electric field (J-E) measurements. A comprehensive and practical 4H-SiC power VDMOSFET manufacturing traveler has been designed. The power MOSFET that was fabricated based on this traveler exhibits less than half of the on-resistance and shows improved interface characteristics compared to a similarly designed commercial power MOSFET.
