Effect of Phosphorus Doped Poly Annealing on Threshold Voltage Stability and Thermal Oxide Reliability in 4H-SiC MOSFET

Abstract:

We have investigated the effect of high temperature annealing of phosphorus doped poly on gate oxide integrity and device reliability. In NMOS capacitance analysis, unstable flat band voltage characteristics and lower oxide breakdown electric field were observed in wafers which received high temperature poly annealing at 1100 °C. Gate oxide integrity (GOI/Vramp) tests and time dependent dielectric breakdown (TDDB) tests were performed to evaluate wafer level reliability. Degraded GOI characteristics and poor gate oxide lifetime were obtained for the high temperature poly annealed condition. To evaluate package level reliability, high temperature gate bias (HTGB) stress tests were conducted. Some samples failed in positive gate bias stress and more severe negative threshold voltage shift was observed in negative gate bias stress for the high temperature poly annealed condition.
