Effect of Mo₂C Addition on the Microstructure and Properties of TiC-High Manganese Steel-Bonded Carbide

Abstract:

TiC-high manganese steel-bonded carbide was prepared by powder metallurgy method with varied Mo₂C content (0, 2.5%, 5%, 7.5% and 10% respectively), and the effects of Mo₂C addition on the microstructure and mechanical properties of the fabricated cermets were studied. The microstructures of the fabricated cermets were observed and analyzed by scanning electron microscope (SEM), and the physical and mechanical properties of the cermets were also tested. The results show that the microstructure of the cermet without Mo₂C additive was finer than that of the cermets with 2.5% and 5% Mo₂C addition, though Mo₂C was an effective grain growth inhibitor of TiC- and/or TiCN-based refractory materials because of low inherent solubility of TiC in Fe binder. An interesting phenomenon was also found that black core-gray rim was observed in the microstructure of the cermet without Mo₂C addition. The microstructure of the fabricated cermets was fine with the increase of Mo₂C content. The results also show that the relative density and hardness of the cermet increased monotonously with the increase of Mo₂C content, hence, the transverse rupture strength (TRS) and impact toughness (IM) of the fabricated cermets increased first and then decreased, and the TRS and IM reached the maximum valve of 2189 MPa and 11.7 J/cm² when Mo₂C content was 7.5% and 5% respectively.

• Periodical: Materials Science Forum (Volume 1035)
• Pages: 752-758
• DOI: https://doi.org/10.4028/www.scientific.net/MSF.1035.752
• Online since: June 2021
• Authors: Li Bo Guo, Jun Chao He, Guo Ping Li*, Lian Wu Yan
• Keywords: Microstructure, Mo₂C Addition, Properties, Steel-Bonded Carbide, TiC

References

[1] T.F. Jing, F.C. Zhang, The work-hardening behavior of medium manganese steel under impact abrasive wear condition, J. Mater. Lett. 31 (1997) 275–279.

DOI: 10.1016/s0167-577x(96)00293-5

[2] A.K. Srivastava, K. Das, Microstructure and abrasive wear study of (W,Ti)C reinforced high-manganese austenitic steel matrix composite, J. Mater. Lett. 62 (2008) 3947–3950.

DOI: 10.1016/j.matlet.2008.05.049

[3] B. Liu, S. Huang, J.V. Humbeeck, J. Vleugels, Influence of Mo addition on the microstructure and mechanical properties of TiC-NiTi cermets, J. J Alloys Compd. 712 (2017) 579–587.

DOI: 10.1016/j.jallcom.2017.04.151

[4] S. Cardinal, A. Malchère, V. Garnier, G. Fantozzi, Microstructure and mechanical properties of TiC-TiN based cermets for tools application, J. Int. J. Refract. Met. Hard Mater. 27 (2009) 521–527.

DOI: 10.1016/j.ijrmhm.2008.10.006

[5] X.Q. Wang, X.X. He, H.L. Guo, Influence of Mo on the microstructure and mechanical properties of TiC-based cermets, J. Rare Met. 29 (2010) 346–350.

DOI: 10.1007/s12598-010-0127-y

[6] N. Liu, Y. Xu, Z. Li, M. Chen, G. Li, L. Zhang, Influence of molybdenum addition on the microstructure and mechanical properties of TiC-based cermets with nano-TiN modification, J. Ceram. Int. 29 (2003) 919–925.

DOI: 10.1016/s0272-8842(03)00046-4

[7] S.Q. Zhou, W. Zhao, W.H. Xiong, Y.N. Zhou, Effect of Mo and Mo2C on the microstructure and properties of the cermets based on Ti(C,N), J. Acta Metall. Sin. (Engl. Lett.) 21 (2008) 211–219.

DOI: 10.1016/s1006-7191(08)60041-1

[8] Y. Li, N. Liu, X. Zhang, C. Rong, Effect of Mo addition on the microstructure and mechanical properties of ultra-fine grade TiC-TiN-WC-Mo2C-Co cermets, J. Int. J. Refract. Met. Hard Mater. 26 (2008) 190–196.

DOI: 10.1016/j.ijrmhm.2007.05.005

[9] N. Lin, C.H. Wu, Y.H. He, D.F. Zhang, Effect of Mo and Co additions on the microstructure and properties of WC-TiC-Ni cemented carbides, J. Int. J. Refract. Met. Hard Mater. 30 (2012) 107–113.

DOI: 10.1016/j.ijrmhm.2011.07.011

[10] J. Xiong, Z. Guo, B. Shen, D. Cao, The effect of WC, Mo2C, TaC content on the microstructure and properties of ultra-fine TiC0.7N0.3 cermet, J. Mater. Des. 28 (2007) 1689–1694.

DOI: 10.1016/j.matdes.2006.03.005

[11] T.L. Stewart, K.P. Plucknett, The effects of Mo2C additions on the microstructure and sliding wear of TiC0.3N0.7-Ni3Al cermets, J. Int. J. Refract. Met. Hard Mater. 50 (2015) 227–239.

DOI: 10.1016/j.ijrmhm.2015.01.013

[12] C. Liu, N. Lin, Y.H. He, Influence of Mo2C and TaC additions on the microstructure and mechanical properties of Ti(C,N)-based cermets, J. Ceram. Int. 42 (2016) 3569–3574.

DOI: 10.1016/j.ceramint.2015.10.168

[13] W. Wan, J. Xiong, M. Liang, Effects of secondary carbides on the microstructure, mechanical properties and erosive wear of Ti(C,N)-based cermets, J. Ceram. Int. 43 (2017) 944–952.

DOI: 10.1016/j.ceramint.2016.10.024

[14] S.G. Shin, J.H. Lee, Effect of carbide additions on grain growth in TiC-Ni cermets, J. Met. Mater. Int. 12 (2006) 57–62.

DOI: 10.1007/bf03027524

[15] J. Qu, W. Xiong, D. Ye, Z. Yao, W. Liu, S. Lin, Effect of WC content on the microstructure and mechanical properties of Ti(C0.5N0.5)-WC-Mo-Ni cermets, J. Int. J. Refract. Met. Hard Mater. 28 (2010) 243–249.

DOI: 10.1016/j.ijrmhm.2009.10.005

[16] W. Jun, L. Ying, Z. Ping, P. Jiancai, Y. Jinwen, T. Minjing, Effect of WC on the microstructure and mechanical properties in the Ti(C0.7N0.3)–xWC–Mo2C–(Co, Ni) system, Int. J. Refract. Met. Hard Mater. 27 (2009) 9–13.

DOI: 10.1016/j.ijrmhm.2008.01.010

[17] G. Dong, J. Xiong, J. Chen, Z. Guo, W. Wan, C. Yi, H. Chen, Effect of WC on the microstructure and mechanical properties of nano Ti(C,N)-based cermets, J. Int. J. Refract. Met. Hard Mater. 35 (2012) 159–162.

DOI: 10.1016/j.ijrmhm.2012.05.009

[18] F. Akhtar, I.S. Humail, S.J. Askari, J. Tian, G. Shiju, Effect of WC particle size on the microstructure, mechanical properties and fracture behavior of WC-(W, Ti, Ta) C-6 wt.% Co cemented carbides, J. Int. J. Refract. Met. Hard Mater. 25 (2007) 405–410.

DOI: 10.1016/j.ijrmhm.2006.11.005

[19] S. Mun, S. Kang, Effect of HfC addition on microstructure of Ti(CN)-Ni cermet system, J. Powder Metall. 42 (1999) 251–256.

DOI: 10.1179/003258999665594

[20] J. M. Barranco, R. A. Warenchak, Liquid phase sintering of carbides using a nickel-molybdenum alloy, J. United States: American Powder Metallurgy Institute (1987).

[21] S.Y. Zhang, Titanium carbonitride-based cermets: processes and properties, J. Mater. Sci. Eng., A 163 (1993) 141–148.

[22] Z. Wang, T. Lin, X. He, H. Shao, J. Zheng, X. Qu, Microstructure and properties of TiC-high manganese steel cermet prepared by different sintering processes, J. J. Alloys Compd. 650 (2015) 918–924.

DOI: 10.1016/j.jallcom.2015.08.047
