Simulation, Fabrication and Characterization of 4H-SiC Floating Junction Schottky Barrier Diodes (Super-SBDs)

Abstract:

The calculation for 4H-SiC floating junction Schottky barrier diodes (Super-SBDs) was carried out by device simulation and the optimized device structure was fabricated. The best characteristics of the Super-SBDs were breakdown voltage of 2700V and the specific on-resistance of 2.57m*cm2. The world record of Bariga’s Figure of Merit (BFOM) for SiC-SBD expressed by 4Vbd 2/Ron was improved to 11,354MW/cm2.
