Influence of Roll Speed Schedule on Transverse Wall Thickness Evenness of Shell Elongated by Mandrel Mill

Abstract:

The seamless steel tube continuous rolling process with 8-stand full-floating mandrel is simulated with the aid of commercial FE code MSC. SuperForm. The relationship is analyzed between the distribution of the transverse wall-thickness and the speed schedule of the rollers. The result shows that the transverse evenness of the wall thickness of the tubes can be enhanced by optimizing the speed schedule. Furthermore, by adopting meliorated method to measure the wall-thickness of the shell, the error is reduced while data reliability is increased. When using the existing equipments (mandrel mill), it is an effective way to improve the transverse wall-thickness accuracy of the shell tube by adjusting the speed schedule. Compared with present roll speed schedule, the transverse wall-thickness accuracy can be increased by 10% for the rolling of elongated shell with 152.5mm in OD and 6mm in wall thickness tube under the 3# speed schedule put forward in this paper.

• Periodical: Materials Science Forum (Volumes 654-656)
• Pages: 1311-1314
• DOI: https://doi.org/10.4028/www.scientific.net/MSF.654-656.1311
• Online since: June 2010
• Authors: Sheng Zhi Li, Zhi Chao Zhang, Hai Yan Bao, Zhi Yang Zhou
• Keywords: Coupled Thermo-Mechanical FEM Simulation, Mandrel Mill, Seamless Steel Tube, Speed Schedule, Transverse Wall-Thickness Accuracy

References

[1] Yang Wenjun, Li Xiaohong: Steel Pipe Vol. 26, no. 3(1997), p.48 (in Chinese).

[2] Zhong Qianxia, Liu Songquan: Steel Pipe Vol. 22, no. 5(1993), p.51 (in Chinese).

[3] Planker E, et al.: WERKSTATT BETR No. 6, (1986): p.485.

[4] Vacance M, Masson E and Chenot J L: Journal of Materials Processing Technology Vol. 24, (1990), p.421.

[5] Miguel A Cavaliere, Marcela B Goldschmit and Eduardo N Dvorkin: Computer and Structures, Vol. 79(2001), p. (2075).

[6] Shuji Yamamoto, Kenji Yamada, Shuichi Hamauzu, et al.: Journal of the Japan Society for Technology of Plasticity, Vol. 40, no. 11(1999), p.62.

[7] MSC. MARC 2005, User Manual (MSC Software Corporation 2005).

[8] Chen Lijing, Zhang Chi and Chang Bin: Journal of Northwest Hydro Electric Power Vol. 19, No. 3(2003), p.8 (in Chinese).

[9] Yin Yuande, Li Shengzhi: Journal of Engineering Graphics, No. 1(2006), p.13 (in Chinese). a b.
