Numerical Simulation and Experimental Investigation of Grain Refinement Behavior in Equal Channel Angular Pressing/Extrusion Process

Abstract:

The ultra-fine grained (UFG) materials have been widely investigated due to their mechanical properties such as super high strength and super high plasticity. The finite element simulation schemes are planned for the deformation mechanism of ECAP pressing. It will greatly affect the extrusion process when processing parameter changed such as die geometrical parameters and friction condition. It is considerable to determinate the range of die channel angle and die corner angle during ECAP process, and a moderate die corner angle is usually chosen. The friction condition of the ECAP should be lubricated as good as possible in the pressing on the basis of optimal die geometrical conditions. The ECAP process is a non-uniform shear deformation process in the cross-section of the workpiece for first-pass pressing. There have low angle grain boundaries along the cross-section of the grain microstructures. For the multi-pass pressing, although the pressing pass numbers are same, the processing routes were of important significance on the grain sizes and grain distribution and grain boundaries (GBs) orientations of workpieces. The formation mechanism of nanostructure was given for the ECAP through studying the deformation behavior and dislocation’s evolution. The dislocation is one of the main defects in the processed materials, but the form of the dislocations and its density are difference for different processing route. The processed workpiece with high surface quality, refined grain microstructure and optimization grain boundaries were obtained with optimal processing parameters and routes.

• Periodical: Materials Science Forum (Volumes 667-669)
• Pages: 367-372
• DOI: https://doi.org/10.4028/www.scientific.net/MSF.667-669.367
• Online since: December 2010
• Authors: Shu Bo Xu, Guo Cheng Ren, Gui Qing Wang, Peng Liu
• Keywords: Equal-Channel Angular Pressing (ECAP), Finite Element Analysis (FEA), Processing Route, Refinement Mechanism, Ultrafine Grained

References

[1] V. M. Segal, V.I. Reznikov, A.E. Drobyshevskiy and V.I. Kopylov, Plastic working of metals by simple shear．Russian Metallurgy 19 (1981) 99-105.

[2] V.M. Segal, Severe plastic deformation: simple shear versus pure shear. Mater Sci and Eng A 338 (2002) 331-344.

DOI: 10.1016/s0921-5093(02)00066-7

[3] V.M. Segal, Slip line solutions, deformation mode and loading history during equal channel angular extrusion. Mater Sci and Eng A 345 (2003) 36-46.

DOI: 10.1016/s0921-5093(02)00258-7

[4] V. S. Zhernakov, I. N. Budilov, G. I. Raab, I. V. Alexandrov, R. Z. Valiev, Scripta mater. 44 (2001) 1765–1769.

DOI: 10.1016/s1359-6462(01)00796-5

[5] E.O. Hall, The Deformation and Ageing of Mild Steel: III Discussion of Results, Podc. Phys. Soc. B 64 (1951) 747-753.

DOI: 10.1088/0370-1301/64/9/303

[6] M. Zhao, J.C. Li, Q. Jiang, Hall–Petch relationship in nanometer size range, J. Alloys and Compounds 361(2003) 160-164.

DOI: 10.1016/s0925-8388(03)00415-8

[7] R.Z. Valiev, R.K. Islamgaliev and I.V. Alexandrov, Bulk nanostructured materials from severe plastic deformation，Progr Mater Sci 45(2000) 103-189.

DOI: 10.1016/s0079-6425(99)00007-9

[8] R.Z. Valiev, T.G. Langdon, Principles of equal-channel angular pressing as a processing tool for grain refinement，Progr. Mater. Sci. 51(2006) 881-981.

DOI: 10.1016/j.pmatsci.2006.02.003

[9] Y.T. Zhu, T.C. Lowe, Observations and issues on mechanisms of grain refinement during ECAP process, Mater. Sci. Eng. A 291 (2000) 46-53.

DOI: 10.1016/s0921-5093(00)00978-3

[10] M. Furukawa, Z. Horita, M. Nemoto, T.G. Langdon, The use of severe plastic deformation for microstructural control．Mater. Sci. Eng. A 324 (2002) 82-89.

DOI: 10.1016/s0921-5093(01)01288-6

[11] Z. Horita, K. Matsubara, K. Makii, T.G. Langdon, A two-step processing route for achieving a superplastic forming capability in dilute magnesium alloys, Scripta Mater. 47 (2002) 255-260.

DOI: 10.1016/s1359-6462(02)00135-5

[12] K. Nakashimai,Z. Horitai,M. Nemoto and T.G. Langdon, Influnce of channel angle on the development of ultra-fine grains in Equal-Channel Angular Pressing, Acta Mater. 46 (1998), 1589-1599.

DOI: 10.1016/s1359-6454(97)00355-8
