The Analysis and Testing of the Natural Frequency of Air-Spring Precision Isolation Systems

Abstract:

In order to solve the discordance between the engineering calculated natural frequency and the experimental natural frequency of the air-spring precision isolation system, the dynamic models of the air-spring isolation system were established and the engineering calculated natural frequency was 1.28Hz based on an isolation system. Then, impact experiments were carried out in lab and the experimental natural frequency was 1.22Hz using FFT method. The relative error between the two was less than 5%, which reached the expectations, and the error sources were briefly analyzed. The results of the research in this paper have reference value in designing and manufacturing of the air-spring precision isolation systems.

• Periodical: Materials Science Forum (Volume 694)
• Pages: 650-656
• DOI: https://doi.org/10.4028/www.scientific.net/MSF.694.650
• Online since: July 2011
• Authors: Wen Zhang, Jian Long Yin, Liang Bing Jin, Dong Sheng Li
• Keywords: Air-Spring Isolation System, Analysis and Testing of the Natural Frequency, Engineering Calculations of the Natural Frequency, Natural Frequency of the Isolation System

References

[1] Cheng Yanhong, Yang Xinglong, etc. Experimental analysis of the air-spring dynamic characteristics of the automobiles [J], Automobile Technology, 2002(In Chinese).

[2] Ying Xingjuan, Li Haolin, Ni Zhengji. Research on the dynamic performance of the air-spring vibration isolator [J], Journal of University of Shanghai for Science and Technology, 2006, 28(2): 164~168(In Chinese).

[3] Zhang Jianzhuo, Li Dan, Dong Shen. Research on the instrumental precision isolation systems with ultra-low frequency and nonlinear characteristic in parallel use [J], China Mechanical Engineering, 2004, 15(1): 69~71(In Chinese).

[4] Lee J H, Kim K J. Modeling of nonlinear complex stiffness of dual-chamber pneumatic spring for precision vibration isolation [J], Journal of Sound and Vibration, 2007, 301: 909~926.

DOI: 10.1016/j.jsv.2006.10.029

[5] Kawashima K, Kato T, Sawamoto K, et al. Realization of virtual sub chamber on active controlled pneumatic isolation table with pressure differentiator [J], Precision Engineering, 2007, 31: 139~145.

DOI: 10.1016/j.precisioneng.2006.05.002

[6] Shimozawa Itigyou (Japanese), Nonlinear vertical vibrations model of the air-springs [J], Foreign Rolling Stock, 2009, 46(3): 34~39(In Chinese).

[7] Sheng Ying, Zhao Jianwen, Qiu Yuanying, Influence of the air-spring parameters on the isolation performance [J], Noise and Vibration Control, 2006, 6(3): 22~25(In Chinese).
