Study of 3C-SiC Mechanical Resonators, Filters and Mixers

Abstract:

The design, fabrication and characterisation of flexural-mode 3C-SiC resonators are presented. Single-clamped, double-clamped beams and circular membranes, with aluminium and platinum electrodes patterned on top, have been implemented. The structures’ resonant frequency has been investigated optically when the devices are actuated mechanically and electro-thermally. Electro-thermal mixing of two input electrical signals with two different frequencies has been demonstrated. The temperature stability of the 3C-SiC resonators has been characterised.

• Periodical: Materials Science Forum (Volume 711)
• Pages: 43-50
• DOI: https://doi.org/10.4028/www.scientific.net/MSF.711.43
• Online since: January 2012
• Authors: Enrico Mastropaolo, Rebecca Cheung
• Keywords: Electro-Thermal Actuation, Frequency Stability, Micro-Electromechanical System (MEMS), Mixing, Resonators, Silicon Carbide (SiC)
