Investigation of Die Attach for SiC Power Device for 300°C Applications

Abstract:

The mechanical properties of die attach system SiC/Au-Ge/Au-Ni-Cu-Si3N4 using the eutectic Au-Ge solder (Teut = 356°C) were investigated in a temperature range up to 300°C. The as-resulting structure of the solder is observed to be lamellar with pockets of high concentration of Au close to the interfaces. The shear strength of joint decreases with temperature but, even at 300°C, its value is well higher than the IEC standard. The creep behavior of Au-Ge solder alloy was also investigated at 300°C for different strain levels. The creep curves show a high creep resistance even for high stress level.

• Periodical: Materials Science Forum (Volumes 740-742)
• Pages: 1032-1035
• DOI: https://doi.org/10.4028/www.scientific.net/MSF.740-742.1032
• Online since: January 2013
• Authors: A. Drevin-Bazin, F. Badawi, F. Lacroix, J.F. Barbot
• Keywords: Au-Ge, Creep, Die Attach Materials, Die Shear, High-Temperature, Solder

References

[1] J. Emmerlich, D. Music, P. Eklund, O. Wilhelmsson, U. Jansson, J. M. Schneider, H. Högberg, L. Hultman, J. Acta Materialia 55 (2007) 1479-1488.

DOI: 10.1016/j.actamat.2006.10.010

[2] M. Hecker, R. Hübner, R. Ecke, S. Schulz, H. -J. Engelmann, H. Stegmann, V. Hoffmann, N. Mattern, T. Gessner, E. Zschech, Microelectronic Engineering 64 (2002) 269-277.

DOI: 10.1016/s0167-9317(02)00799-2

[3] W. Dorner, H. Mehrer, P. J Pokela, E. Kolawa and M-A Nicolet, Materials Science and Engineering, B10 (1991) 165-169.

[4] S. Tanimoto, K. Matsui, Y. Zushi, S. Sato, Y. Murakami, M. Takamori and T. Iseki, Mater. Sci. Forum 853, 717-720, (2012).

DOI: 10.4028/www.scientific.net/msf.717-720.853

[5] P. Zheng, A. Wiggins, and R.W. Johnson, R. Frampton, S. J. Adam, L. Peltz, Die Attach for High Temperature Electronics Packaging, International Conference on High Temperature Electronics (HiTEC 2008), Albuquerque, New Mexico USA May 12-15 (2008).

[6] F. P. McCluskey , M. Dash , Z. Wang , and D. Huff, Microelectronics Reliability 46, N°9-11, 1910–1914 (2006).

DOI: 10.1016/j.microrel.2006.07.090

[7] R. Wayne Johnson and John Williams, Mater. Sci. Forum 483-485, 785-790 (2005).

[8] Y. Yamada, Y. Takaku, Y. Yagi, Y. Nishibe, I. Ohnuma, Y. Sutou, R. Kainuma and K. Ishida, Microelectronics Reliability 46 1932–1937 (2006).

DOI: 10.1016/j.microrel.2006.07.083

[9] MIL STD 883 method (2012).

[10] S. Tanimoto, K. Matsui, Y. Murakami, H. Yamaguchi and H. Okumura, Proceedings, IMAPS International Conference and Exhibition on High Temperature Electronics 2010 (Albuquerque, NM, USA), 32-39 (2010).

[11] V. Chidambaram, J. Hald, J. Hattel, J. Alloys and Compounds 490 170-179 (2010).

[12] G.S. Zhang, H.Y. Jing, L.Y. Xu, J. Wei, Y.D. Han, J. Alloys and Compounds 476 138-141 (2009).

[13] J. Villain, O.S. Brueller, T. Qasim, Sensors and Actuators A 99 194-197 (2002).
