Impact of AlN Spacer on Electron Mobility of AlGaN/AlN/GaN Structures on Silicon

Abstract:

The impact of the thickness of an AlN spacer in AlGaN/AlN/GaN high electron mobility transistor (HEMT) structures on the Hall mobility was investigated in a range of 30 K - 340 K. The AlN spacer has a strong impact on the mobility at temperatures below 150 K. This effect is linked to a reduction of alloy scattering. Optical and scanning electron microscopy revealed hexagonal shaped defects which also have an effect on the mobility. These defects can be avoided by an appropriate adjustment of the AlN layer thickness.
