4H-Silicon Carbide p-n Diode for High Temperature (600 °C) Environment Applications

Abstract:

In this work, we demonstrate the stable operation of 4H-silicon carbide (SiC) p-n diodes at temperature up to 600 °C. In-depth study methods of simulation, fabrication and characterization of the 4H-SiC p-n diode are developed. The simulation results indicate that the turn-on voltage of the 4H-SiC p-n diode changes from 2.7 V to 1.45 V as the temperature increases from 17 °C to 600 °C. The turn-on voltages of the fabricated 4H-SiC p-n diode decreases from 2.6 V to 1.3 V when temperature changes from 17 °C to 600 °C. The experimental I-V curves of the 4H-SiC p-n diode from 17 °C to 600 °C agree with the simulation ones. The demonstration of the stable operation of the 4H-SiC p-n diodes at high temperature up to 600 °C brings great potentials for 4H-SiC devices and circuits working in harsh environment electronic and sensing applications.
