Interpenetrating Freeze Cast Composites: Correlation between Structural and Mechanical Characteristics

Abstract:

Ceramic freeze cast preforms based on alumina show an anisotropic behavior due to directional freezing during preform production. Beside the specific characteristics such as alumina content and lamellae spacing also the distribution of the so-called domains – regions with a relatively homogeneous orientation of alumina lamellae – play an important role considering stiffness and strength. The gas pressure infiltration process was used for infiltrating the freeze cast preforms with a eutectic aluminum/silicon alloy with a low melting point. Selected regions taken from the freeze cast preform have been analyzed via X-ray micro computed tomography (µCT) prior to the infiltration due to a higher contrast in comparison to the infiltrated preforms. The orientation of the lamellae has been determined from the three dimensional data with an algorithm which is based on the structure tensor. The mechanical stability - in terms of the strength - of the infiltrated preforms has been quantified via quasi static compression tests on cuboid samples. The results show a good agreement between the orientation of the lamellae distribution and the maximum strength of the preform which could also be verified using an analytical model.

• Periodical: Materials Science Forum (Volumes 825-826)
• Pages: 109-116
• DOI: https://doi.org/10.4028/www.scientific.net/MSF.825-826.109
• Online since: July 2015
• Authors: Matthias Merzkirch*, Pascal Pinter, Stefan Dietrich, Kay André Weidenmann
• Keywords: Compression Test, Computer Tomography, Gas Pressure Infiltration, MMC

References

[1] D.B. Miracle, Metal matrix composites – From science to technological significance, Compos. Sci. Technol. 65 (2005) 2526–2540.

DOI: 10.1016/j.compscitech.2005.05.027

[2] S. Deville, Freeze-Casting of Porous Ceramics: A Review of Current Achievements and Issues, Adv. Eng. Mater. 10 (2008) 155-169.

DOI: 10.1002/adem.200700270

[3] V. Michaud, A. Mortensen, On measuring wettability in infiltration processing, Scr. Mater. 56 (2007) 859–862.

DOI: 10.1016/j.scriptamat.2007.02.002

[4] T. Ziegler, A. Neubrand, S. Roy, A. Wanner, R. Piat, Elastic constants of metal/ceramic composites with lamellar microstructures: Finite element modelling and ultrasonic studies, Comp. Scie. & Tech. 69 (2009) 620-626.

DOI: 10.1016/j.compscitech.2008.12.009

[5] T. Waschkies, R. Oberacker, M. J. Hoffmann, Control of Lamellae Spacing During Freeze Casting of Ceramics Using Double-Side Cooling as a Novel Processing Route, J. Am. Ceram. Soc. 92 (2009) S79–S84.

DOI: 10.1111/j.1551-2916.2008.02673.x

[6] S. Roy, A. Wanner, Metal/ceramic composites from freeze-cast ceramic preforms: Domain structure and elastic properties, Compos. Sci. Technol. 68 (2008) 1136–1143.

DOI: 10.1016/j.compscitech.2007.06.013

[7] M. Krause, J. M Hausherr, B. Burgeth, C. Herrmann, W. Krenkel, Determination of the fibre orientation in composites using the structure tensor and local X-ray transform, J. Mater. Sci. 45 (2010) 888–896.

DOI: 10.1007/s10853-009-4016-4

[8] M. Merzkirch, Ch. Blümel, R. Rössler, K. G. Schell, E. C. Bucharsky, K. A. Weidenmann, Manufacturing and Characterization of Interpenetrating SiC Lightweight Composites. Procedia CIRP, International Conference on Manufacture of Lightweight Components – ManuLight2014, 18, (2014).

DOI: 10.1016/j.procir.2014.06.115

[9] M. Merzkirch, A. Reeb, K. A. Weidenmann, V. Schulze, Charakterisierung des Verformungs- und Schädigungsverhaltens unidirektional drahtverstärkter Aluminium- und Magnesium-matrixverbunde unter Zug- und Druckbeanspruchung, in B. Wielage (Eds. ), Tagungsband zum 18. Symposium Verbundwerkstoffe und Werkstoffverbunde in Chemnitz 2011. - Chemnitz: Eigenverlag, 2011, 103-108.

DOI: 10.1002/9783527609017.ch13

[10] M. Merzkirch, Y. Sinchuk, K. A. Weidenmann, R. Piat, Experimental and Numerical Determination of the Elastic Moduli of Freeze Cast MMC with Different Lamellae Orientation, Proceedings to 39th International Conference and Expo on Advanced Ceramics and Composites, 2015, to be published.

DOI: 10.1002/9781119211747.ch13

[11] S. Roy, B. Butz, A. Wanner, Damage evolution and domain-level anisotropy in metal/ceramic composites exhibiting lamellar microstructures, Acta Materialia 58 (2010) 2300–2312.

DOI: 10.1016/j.actamat.2009.12.015

[12] D. Agarwal, L. J. Broutman, Analysis and Performance of Fiber Composites, John Wiley & Sons, Inc., 1990, pp.178-181.
