Progress on Preparation of InAs Nanowires by Molecular Beam Epitaxy

Abstract:

InAs nanowires (NWs) is a key material for high-speed electronics, near-and mid-infrared light emission and detection applications. Much effort has been devoted to the fabrication of InAs NWs and molecular beam epitaxy (MBE) evolved as a powerful method to grow semiconductor nanowires with several interesting features, but it was rarely reported. We present kinds of growths (metal-catalyzed growth, self-catalyzed growth, self-induced free-standing growth, self-induced position-controlled growth, self-assisted nucleation growth etc.) of InAs NWs by MBE, and discuss how to control growth of uniform-structure InAs NWs on homogeneous or heterogeneous substrates, which can provide the reference for the manufacture of low dimensional structure.

• Periodical: Materials Science Forum (Volume 852)
• Pages: 349-355
• DOI: https://doi.org/10.4028/www.scientific.net/MSF.852.349
• Online since: April 2016
• Authors: Ru Xue Li, Ji Long Tang, Dang Fang, Shuang Peng Wang, Hai Feng Zhao, Xuan Fang, Zhi Peng Wei, Hui Min Jia, Xiao Hua Wang, Xiao Hui Ma
• Keywords: Application, Growth, InAs Nanowires, MBE
