Improvement of 4H-SiC Epitaxial Layers Grown on 2^o Offcut Si-Face Substrates

Abstract:

The surface quality of epitaxial layers grown on 2° offcut substrates was improved. These substrates require a lower growth temperature and a lower C/Si ratio than their 4° offcut counterparts to suppress macro step bunching. Surface morphology, triangular defect density, and doping uniformity presented a trade-off relationship with respect to growth parameters. The implementation of a low C/Si ratio buffer layer led to a balance between surface defect density, which reached a minimum of 0.2 cm⁻², and good doping uniformity on an equivalent wafer size (150 mm). An evaluation of metal–oxide–semiconductor capacitors and Schottky barrier diodes fabricated on 2° offcut epitaxial layers showed that the quality of these epitaxial layers was satisfactory for application in devices.
